79
IPSG1703
P3000 K1KY06AA1356 6P CONNECTOR 1
JACKS
JK3000 K2HC1YYB0033 JK HEADPHONE 1
RESISTORS
R3000 D0GB471JA065 470 1/10W 1
R3001 D0GB471JA065 470 1/10W 1
PRINTED CIRCUIT
BOARDS
PCB10 REP4945B CD INTERFACE
P.C.B
1 (RTL)
SWITCHES
S7201 K0L1BA000158 SW 1
CONNECTOR
CN7001 K1MY05BA0565 5P CONNECTOR 1
CN7002 K1MN10B00016 10P CONNECTOR 1
PRINTED CIRCUIT
BOARDS
PCB11 REP5310A DAB P.C.B 1 (RTL)
152EGS
INTEGRATED CIR-
CUITS
IC1 RFKWFCRS32EB IC 1 152EGS
IC2 C1CB00004533 IC 1 152EGS
CAPACITORS
C2 F1G1H560A834 56pF 50V 1 152EGS
C3 F1G1H330A834 33pF 50V 1 152EGS
C4 F1G1H560A834 56pF 50V 1 152EGS
C8 F1G1A1040006 0.1uF 10V 1 152EGS
C9 F1G1A1040006 0.1uF 10V 1 152EGS
C10 F1G1A1040006 0.1uF 10V 1 152EGS
C11 F1H0J4750004 4.7uF 6.3V 1 152EGS
C12 F1G1A1040006 0.1uF 10V 1 152EGS
C13 F1H0J4750004 4.7uF 6.3V 1 152EGS
C14 F1G1A1040006 0.1uF 10V 1 152EGS
C16 F1G1A1040006 0.1uF 10V 1 152EGS
C17 F1H0J4750004 4.7uF 6.3V 1 152EGS
C18 F1G1A1040006 0.1uF 10V 1 152EGS
C19 F1G1A1040006 0.1uF 10V 1 152EGS
C20 F1G1A1040006 0.1uF 10V 1 152EGS
C21 F1G1A1040006 0.1uF 10V 1 152EGS
C22 F1G1A1050004 1uF 10V 1 152EGS
C23 F1G1H223A739 0.022uF 50V 1 152EGS
C24 F1H1H223B047 0.022uF 50V 1 152EGS
C25 F1G1A1050004 1uF 10V 1 152EGS
C27 F1G1A1050004 1uF 10V 1 152EGS
C29 F1G1C103A146 0.01uF 16V 1 152EGS
C32 F1G1A1040006 0.1uF 10V 1 152EGS
C33 F1G1A1040006 0.1uF 10V 1 152EGS
C37 F1G1C103A146 0.01uF 16V 1 152EGS
C38 F1G1A1040006 0.1uF 10V 1 152EGS
C41 F1G1H471A541 470pF 50V 1 152EGS
C42 F1G1H471A541 470pF 50V 1 152EGS
C43 F1G1A1050004 1uF 10V 1 152EGS
C47 F1G1A1050004 1uF 10V 1 152EGS
C48 F1G1H102A830 1000pF 50V 1 152EGS
C49 F1G1H223A739 0.022uF 50V 1 152EGS
C50 F1G1H3R3A784 3.3pF 50V 1 152EGS
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
COIL AND INDUC-
TORS
L2 J0JYC0000051 INDUCTOR 1 152EGS
L3 G1C68NJA0037 INDUCTOR 1 152EGS
L4 G1CR12GA0007 INDUCTOR 1 152EGS
L5 G1CR22GA0007 INDUCTOR 1 152EGS
LB7 J0JYC0000051 INDUCTOR 1 152EGS
LB8 J0JYC0000051 INDUCTOR 1 152EGS
OSCILLATORS
X1 H0J384500002 OSCILLATORS 1 152EGS
JACKS
JK1 K4AK01Z00002 JK 1 152EGS
CONNECTORS
CN1 K1MN10AA0046 10P CONNECTOR 1 152EGS
RESISTORS
R4 D0GA330JA023 33 1/16W 1 152EGS
R5 D0GA330JA023 33 1/16W 1 152EGS
R6 D0GA330JA023 33 1/16W 1 152EGS
R13 D0GA101JA023 100 1/16W 1 152EGS
R15 D0GA103JA023 10K 1/16W 1 152EGS
R18 D0GA201JA023 200 1/16W 1 152EGS
R19 D0GA101JA023 100 1/16W 1 152EGS
R20 D0GA101JA023 100 1/16W 1 152EGS
R21 D0GAR00J0008 0 1/16W 1 152EGS
R22 D0GAR00J0008 0 1/16W 1 152EGS
R23 D0GA100JA023 10 1/16W 1 152EGS
R27 D0GA100JA023 10 1/16W 1 152EGS
R34 D0GAR00J0008 0 1/16W 1 152EGS
R41 D0GA104JA023 100K 1/16W 1 152EGS
R46 D0GA101JA023 100 1/16W 1 152EGS
R47 D0GA682JA023 6.8K 1/16W 1 152EGS
R48 D0GA224JA023 220K 1/16W 1 152EGS
R51 D0GAR00J0008 0 1/16W 1 152EGS
R52 D0GA104JA023 100K 1/16W 1 152EGS
PRINTED CIRCUIT
BOARDS
PCB12 RFKZPMX150EG ALLPLAY MODULE
WITH DATA
1 150EGS,
150PCS
PCB12 RFKZPMX152EG ALLPLAY MODULE
WITH DATA
1 152EGS
