Panasonic SA-PT160E - Component Parts List

25.1. Component Parts List
Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 J3CBBC000001 TUNER PACK [M]
2 L6FAJCCH0007 FAN MOTOR [M]
3 REEX0726 50P FFC CABLE (MECHA) [M]
4 REEX0679 5P FFC CABLE (MECHA-USB) [M]
5 REEX0736 13P FFC WIRE (FL) [M]
7 REXX0384-J 7P FLAT WIRE (DVD) [M]
8 REXX0519 4P FLAT WIRE (VOL) [M]
9 REXX0520 11P FLAT WIRE (MN) [M]
10 REXX0521 4P FLAT WIRE (MN) [M]
12 REXX0589 5P USB WIRE [M]
13 RGKX0325A-S1 DVD LID [M]
E/EG-S
13 RGKX0325A1K1 DVD LID [M]
E/EB/EG
-K
14 RGLX0128-Q LIGHTING CHIP [M]
15 RFKGAPT160ES FRONT PANEL ASS´Y [M]
E/EG-S
15 RFKGAPT160EB FRONT PANEL ASS´Y [M] EB-
K
15 RFKGAPT160EG FRONT PANEL ASS´Y [M]
EG/E-K
16 RGRX0058E-P REAR PANEL [M]
E/EG-
S/K
16 RGRX0058E-Q REAR PANEL [M] EB-
K
17 RGUX0665-S POWER BUTTON [M]
E/EG-S
17 RGUX0665-1K POWER BUTTON [M]
E/EB/EG
-K
18 RGUX0666-S FUNCTION BUTTON [M]
E/EG-S
18 RGUX0666-1K FUNCTION BUTTON [M]
E/EB/EG
-K
19 RGUX0676-S OPEN CLOSE BUTTON [M]
E/EG-S
19 RGUX0676-1K OPEN CLOSE BUTTON [M]
E/EB/EG
-K
20 RGWX0076-S VOLUME KNOB [M]
E/EG-S
20 RGWX0076-1KJ VOLUME KNOB [M]
E/EB/EG
-K
21 RHD26046 SCREW [M]
22 RHD30007-1SJ SCREW [M]
E/EG-S
22 RHD30007-K2J SCREW [M]
E/EB/EG
-K
23 RHD30092-1 SCREW [M]
24 RHD30111-3 SCREW [M]
25 RHD30119-S SCREW [M]
26 RHDV30006 SCREW [M]
27 RKA0059-K LEG FELT [M]
28 RKMX0107-1S3 TOP CABINET [M]
E/EG-S
28 RKMX0107-K3 TOP CABINET [M]
E/EB/EG
-K
29 RMAX0086-2 PANEL ANGLE [M]
30 RMAX0101 BRACKET [M]
31 RMAX0108-1 MECHA HOLDER [M]
32 RMKX0117-4 BOTTOM CHASSIS [M]
33 RMNX0109 PCB SPACER [M]
34 RMNX0149 FL HOLDER [M]
35 RMYX0191A HEATSINK EXTRUSION [M]
36 RMZX0029 MAIN PCB INSOLATOR [M]
37 RXXX0090 HEATSINK UNIT [M]
39 XTB3+8JFJ SCREW [M]
Ref.
No.
Part No. Part Name & Description Remarks
40 N0AZ6GE00005 SMPS MODULE [M]
(RTL)
TRAVERSE DECK
310 RMK0591A MECHA CHASSIS [M]
311 RHM0003-J MAGNET [M]
312 RDG0547 PULLEY GEAR [M]
313 RDG0548-1 RELAY GEAR [M]
314 RDG0549 DRIVE GEAR [M]
315 RDV0070 BELT [M]
316 REM0133 MOTOR UNIT [M]
317 RGQ0395-K1 TRAY [M]
318 RME0350 CHANGE LEVER SPRING [M]
319 RME0351A LOCK LEVER SPRING [M]
320 RME0353 TRAY SLIDER SPRING [M]
321 RML0627-2 DRIVE ARM [M]
322 RML0628 CHANGE LEVER [M]
323 RML0629 LOCK LEVER [M]
324 RML0631 TRAY SLIDER [M]
325 RMM0247-3 DRIVE RACK [M]
326 RMM0248 SUB RACK [M]
327 RMR1446-X CLAMPER [M]
328 RMR1447-X MAGNET HOLDER [M]
329 RMR1468-K CLAMP PLATE [M]
330 XTN26+6GFJ SCREW [M]
331 XTV2+6GFJ SCREW [M]
332 XWG6FFJ WASHER [M]
333 RMC0387 SUPPORT SPRING [M]
340 RAE2023Z-S TRAVERSE UNIT [M]
(RTL)
341 RMG0598A-K FLOATING RUBBER [M]
342 RMR1596-X2 MIDDLE CHASSIS [M]
343 RMS0789 FIXED PIN [M]
PRINTED CIRCUIT BOARDS
PCB1 REPX0562A DVD MODULE P.C.B [M]
(RTL)
PCB2 REPX0581G MAIN P.C.B [M]
(RTL) E
REPX0581B MAIN P.C.B [M]
(RTL)
EB
REPX0581A MAIN P.C.B [M]
(RTL)
EG
PCB3 REPX0581G TUNER EXTENT P.C.B [M]
(RTL) E
REPX0581B TUNER EXTENT P.C.B [M]
(RTL)
EB
REPX0581A TUNER EXTENT P.C.B [M]
(RTL)
EG
PCB4 REPX0581G VOLUME P.C.B [M]
(RTL) E
REPX0581B VOLUME P.C.B [M]
(RTL)
EB
REPX0581A VOLUME P.C.B [M]
(RTL)
EG
PCB5 REPX0581G PANEL P.C.B [M]
(RTL) E
REPX0581B PANEL P.C.B [M]
(RTL)
EB
REPX0581A PANEL P.C.B [M]
(RTL)
EG
PCB6 REPX0581G USB P.C.B [M]
(RTL) E
REPX0581B USB P.C.B [M]
(RTL)
EB
96
SA-PT160E / SA-PT160EB / SA-PT160EG
