Ref. No. Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEX0202 10P FFC [M]
3 REEX0273 30P FFC WIRE [M]
4 REEX0274 19P FFC WIRE [M]
5 REEX0275 14P FFC WIRE [M]
6 REEX0276 17P FFC WIRE [M]
7 REEX0277 15P FFC WIRE [M]
8 REEX0278 26P FFC WIRE [M]
9 REEX0279-1J 50P FFC WIRE [M]
10 REEX0280 14P FFC WIRE [M]
11 L6FALEFH0023 FAN [M]
13 RYFX0133C-S CONTROL PANEL [M]
14 RGLX0069-Q POWER LIGHT CHIP [M]
15 RFKGAVK61DEE FRONT PANEL ASS’Y [M]
16 RGRX0029G-B REAR PANEL [M]
17 RGUX0527-S POWER BUTTON [M]
18 RGUX0528-S DECK 1/2 CONTROL BT [M]
19 RGUX0529-S CONTROL BUTTON [L] [M]
20 RGUX0530-S CONTROL BUTTON [R] [M]
21 RGUX0531A-1S FUNCTION BOTTON [L] [M]
22 RGUX0532B-1S FUNCTION BTTON [R] [M]
23 RGUX0533-S PRESET EQ BUTTON [M]
24 RGUX0534A-Q SS EQ BUTTON [M]
25 RGUX0535-S CD EJECT BUTTON [M]
26 RGUX0537-Q DPL BUTTON [M]
27 RGWX0056-S MIC VOL KNOB [M]
28 RGWX0080-S VOLUME KNOB [M]
29 RHD30004-2S SCREW [M]
Ref. No. Part No. Part Name & Description Remarks
PRINTED CIRCUIT BOARD
REP3406B-N DVD MODULE (1) P.C.B.
(COMPONENT SIDE & FOIL
SIDE)
[M](RTL)
REP3587H DVD MODULE (2) P.C.B.
(SIDE A & B)
[M](RTL)
REPX0376K MAIN P.C.B. [M](RTL)
REPX0376K TUNER EXTENT P.C.B. [M](RTL)
REPX0378N PANEL P.C.B. [M](RTL)
REPX0378N LED P.C.B. [M](RTL)
REPX0378N TACT P.C.B. [M](RTL)
REPX0373C TUNER P.C.B. [M](RTL)
REP1999B TUNER PACK [M](RTL)
REPX0331A DECK P.C.B. [M](RTL)
REPX0321B DECK MECHANISM P.C.B. [M](RTL)
REPX0377F POWER SUPPLY P.C.B. [M](RTL)
REPX0377F POWER P.C.B. [M](RTL)
REPX0379C TRANSFORMER P.C.B. [M](RTL)
REPX0379C AC INLET P.C.B. [M](RTL)
REPX0379C VOLTAGE SELECTOR P.C.B. [M](RTL)
REP2578A-N CD LOADING P.C.B. [M](RTL)
REP2578A-N CD DETECT P.C.B. [M](RTL)
REP2578A-N SPINDLE POSITION P.C.B. [M](RTL)
INTEGRATED CIRCUITS
IC1 C0GAM0000005 IC MOTOR DRIVE [M]
IC2 C0CBADG00005 IC 5V REGULATOR [M]
IC3 C0DBAMH00009 IC POWER SUPPLY [M]
IC4 C0DBAMH00009 IC POWER SUPPLY [M]
IC5 C0DBZHE00017 IC POWER SUPPLY [M]
IC6 C0CBADG00005 IC 5V REGULATOR [M]
IC8 C0DBCFG00004 IC 1.5V REGULATOR [M]
IC9 C0CBADG00005 IC 5V REGULATOR [M]
IC50 C9ZB00000377 IC VIDEO BUFFER [M]
IC101 LA1833NMNTLM IC IF & MPX IC [M]
IC102 LC72131MDTRM IC PLL [M]
IC301 C0JZAS000004 IC ANALOG SWITCH [M]
IC302 KIA4558FEL IC DUAL OP-AMP [M]
Ref. No. Part No. Part Name & Description Remarks
30 RHD30078 SCREW [M]
31 RJFX0003 PCB HOLDER [M]
32 RKA0059-K LEG RUBBER [M]
33 RKFX0093-K CASS. HOLDER [L] [M]
34 RKFX0094-K CASS. HOLDER [R] [M]
35 RKMX0077B-S TOP CABINET (BEND) [M]
36 RKWX0210A-V FL WINDOW [M]
37 RMBX0021 CASS OPEN SPRING [M]
38 RMC0158-S TR-FIXTURE [M]
39 RMCX0020 REGULATOR IC CLIP [M]
40 RMKX0062 BOTTOM CHASSIS [M]
41 RMKX0075-1 DVD CHASSIS [M]
42 RMNX0019 PCB SPACER [M]
43 RMNX0029C-A SUB TRANS HOLDER [M]
44 RUS757ZAA CASSETTE HALF SPRING [M]
45 RXGX0002 DAMPER GEAR [M]
46 RYFX0127-S CASS LID UNIT [L] [M]
47 RYFX0128-S CASS LID UNIT [R] [M]
48 RYQX0094C-S TOP ORNAMENT UNIT [M]
49 RYQX0110 5 CD CONTROL BTN [M]
50 SHE187-5J PCB SUPPORT [M]
51 XTB3+10JFZ SCREW [M]
52 XTB3+20J SCREW [M]
53 XTBS26+10J SCREW [M]
54 XTBS3+8JFZ1 SCREW [M]
55 XTW3+8T SCREW [M]
56 RYQX0093B-S CD LID UNIT [M]
57 XTW3+15T SCREW [M]
Ref. No. Part No. Part Name & Description Remarks
IC306 KIA4558FEL IC DUAL OP-AMP [M]
IC307 C1BB00000782 IC 6-CHANNEL VOLUME [M]
IC308 C0AABB000117 IC OP-AMP [M]
IC500 RSN312H24-P IC POWER HIC [M]
IC501 C5BA00000113 IC VOLTAGE REGULATOR [M]
IC600 C2BBHF000076 IC MICROPROCESSOR [M]
IC601 C1BB00000574 IC I/O EXPANDER [M]
IC603 C1BB00000086 IC SPECTRUM ANALYZER [M]
IC604 C1BB00000574 IC I/O EXPANDER [M]
IC700 C2HBZC000013 IC DSP [M]
IC701 M62456FPE1 IC DIGITAL SOUND
CONTROLLER
[M]
IC702 C1BB00000801 IC KARAOKE [M]
IC703 C1BB00000574 IC I/O EXPANDER [M]
IC951 CNB13030R2AU IC PHOTO INTERRUPTER [M]
IC971 CNB13030R2AU IC PHOTO INTERRUPTER [M]
IC1001 AN7348S-E1 IC P.B EQ/REC AMP/
ALC/TPS AMP
[M]
IC1004 C1AA00000612 IC R/P SELECT [M]
IC2501 C0GBG0000033 IC MOTOR DRIVE [M]
IC3001 MN2DS0002AP1 IC AV DECODER [M]
IC3051 C3ABPJ000017 IC 64M SDRAM [M]
IC4201 C0FBBK000035 IC 2CH D/A CONVERTER [M]
IC6201 C0EBE0000070 IC RESET [M]
IC6251 C0CBCBE00003 IC REGULATOR [M]
IC6261 C0JBAA000001 IC INVERTER [M]
IC6262 C0JBAA000001 IC INVERTER [M]
IC6301 RFKFMV71W160 IC 16M FLASH [SPC]
IC6561 C1DB00000980 IC CLOCK GENERATOR [M]
TRANSISTORS
Q1 2SK544F-AC TRANSISTOR [M]
Q1 B1GACFGG0004 TRANSISTOR [M]
Q2 2SC2786MTA TRANSISTOR [M]
Q3 2SC2787FL1TA TRANSISTOR [M]
Q4 2SC2787FL1TA TRANSISTOR [M]
Q4 B1BBCF000006 TRANSISTOR [M]
Q5 B1ADCF000001 TRANSISTOR [M]
25.3.2. Cabinet Parts List
25.4. Electrical Parts List
141
SA-VK61DGS
