Panasonic SA-VKX95EE - Main PCB Voltage Measurements

91
14.1.5. Main P.C.B. Ass'y (1/5)
REF NO.
MODE 1234567891011121314151617181920
PLAY 3.3 3.3 3.3 3.3 1.4 3.3 0 3.3 3.3 0 3.3 0 0 3.3 0 0 3.3 1.6 0 0
STANDBY 3.3 3.3 3.3 3.3 1.4 3.3 0 3.3 3.3 0 3.3 0 0 3.3 0 0 3.3 1.6 0 0
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
PLAY 3 3.3 0.1 3 0 0.6 3.2 2.2 3.3 0 3.3 0.1 1.6 1.6 0.9 0 0 1.3 1.3 0.2
STANDBY 3 3.3 0.1 3 0 0.6 3.2 2.2 3.3 0 3.3 0.1 1.6 1.6 0.9 0 0 1.3 1.3 0.2
REF NO.
MODE 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
PLAY 0.7 0 3.3 3.3 1.1 1.1 3.3 3.3 3.3 1.7 1.7 1.7 0 1.6 1.6 1.4 1.4 0.1 0.5 1.6
STANDBY 0.7 0 3.3 3.3 1.1 1.1 3.3 3.3 3.3 1.7 1.7 1.7 0 1.6 1.6 1.4 1.4 0.1 0.5 1.6
REF NO.
MODE 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
PLAY 1.7 1.7 1.7 1.7 1.7 0 1.5 1.5 1.5 1.5 0 0 3.3 3.3 3.3 3.3 1.7 3.3 3.3 0
STANDBY 1.7 1.7 1.7 1.7 1.7 0 1.5 1.5 1.5 1.5 0 0 3.3 3.3 3.3 3.3 1.7 3.3 3.3 0
REF NO.
MODE 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100
PLAY 0 1.7 1.7 0.9 0 3.3 1.4 3.3 3.3 0 0 1.6 0 3.2 0 3.3 0000
STANDBY 0 1.7 1.7 0.9 0 3.3 1.4 3.3 3.3 0 0 1.6 0 3.2 0 3.3 0000
REF NO.
MODE 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120
PLAY 1.6 3.3 3.3 0 3.1 3.1 3.3 3.3 2 1.7 1.7 1.5 3.3 0 0 3.3 3.3 3.3 3.3 3.3
STANDBY 1.6 3.3 3.3 0 3.1 3.1 3.3 3.3 2 1.7 1.7 1.5 3.3 0 0 3.3 3.3 3.3 3.3 3.3
REF NO.
MODE 121 122 123 124 125 126 127 128
PLAY 3.3 3.3 0 1.5 1.6 0 1.4 1.5
STANDBY 3.3 3.3 0 1.5 1.6 0 1.4 1.5
REF NO.
MODE 12345
PLAY 3.3 3.3 0 0 1.9
STANDBY 3.3 3.3 0 0 1.9
REF NO.
MODE 12345678910111213141516
PLAY 0 1.2 0.8 1.2 1.6 1.6 1.6 0 1.6 1.7 1.6 0 0 0 0 3.3
STANDBY 0 1.2 0.8 1.2 1.6 1.6 1.6 0 1.6 1.7 1.6 0 0 0 0 3.3
REF NO.
MODE 12345678910
PLAY 10.9 39.5 3.1 2.1 0.5 0 0.8 0.7 0 4.7
STANDBY 10.9 39.5 3.1 2.1 0.5 0 0.8 0.7 0 4.7
REF NO.
MODE 12345678910
PLAY 10.9 39.5 3.1 2.1 0.5 0 0.8 0.7 0 4.7
STANDBY 10.9 39.5 3.1 2.1 0.5 0 0.8 0.7 0 4.7
REF NO.
MODE 12345678
PLAY 8.6 1.6 1.6 0 1.6 1.6 8.6 15.3
STANDBY 8.6 1.6 1.6 0 1.6 1.6 8.6 15.3
SA-VKX95GA/GS/EE MAIN P.C.B. ASS'Y
IC1001
IC1001
IC1002
IC1005
IC2100
IC2101
IC2102
IC1001
IC1001
IC1001
IC1001
IC1001
