Panasonic SA-VKX95EE - Page 92

92
14.1.6. Main P.C.B. Ass'y (2/5)
REF NO.
MODE 12345678910
PLAY 21.3 39.5 3.1 2.1 0.5 0 0.8 0.7 0 15.2
STANDBY 21.3 39.5 3.1 2.1 0.5 0 0.8 0.7 0 15.2
REF NO.
MODE 1 2 3
PLAY 0 3.3 5.5
STANDBY 0 3.3 5.5
REF NO.
MODE 1 2 3
PLAY 15.4 0 9.2
STANDBY 15.4 0 9.2
REF NO.
MODE 1234
PLAY 3.3 0 1.6 3.3
STANDBY 3.3 0 1.6 3.3
REF NO.
MODE 1 2 3
PLAY 0 3.3 5
STANDBY 0 3.3 5
REF NO.
MODE 1234567891011121314151617181920
PLAY 0 3.3 3.3 3.3 3.3 0 0 - 1 3.3 1.7 0 1.4 3.3 1.7 00002.8
STANDBY 0 3.3 3.3 3.3 3.3 0 0 - 1 3.3 1.7 0 1.4 3.3 1.7 00002.8
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
PLAY 3 1.6 0 0 0 3.2 2.2 0.6 0 3.3 0 0 3.3 3.3 000000
STANDBY 3 1.6 0 0 0 3.2 2.2 0.6 0 3.3 0 0 3.3 3.3 000000
REF NO.
MODE 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
PLAY 0 0 0 3.3 000003.33.30003.300003.3
STANDBY 0 0 0 3.3 000003.33.30003.300003.3
REF NO.
MODE 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
PLAY 0 0 3.3 00000000000000000
STANDBY 0 0 3.3 00000000000000000
REF NO.
MODE 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100
PLAY 0000000.421.51.501.51.501.53.33.303.23.3
STANDBY 0000000.421.51.501.51.501.53.33.303.23.3
REF NO.
MODE 1234567891011121314151617181920
PLAY 12.2 12.1 1.2 0 1.7 1.7 3.3 000007.83.303.33.3000
STANDBY 12.2 12.1 1.2 0 1.7 1.7 3.3 000007.83.303.33.3000
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
PLAY 3.3 12 30.1 30.1 0 0 19 19 39.5 39.5 39.5 19 0 0 19 39.5 39.5 39.5 19 19
STANDBY 3.3 12 30.1 30.1 0 0 19 19 39.5 39.5 39.5 19 0 0 19 39.5 39.5 39.5 19 19
IC2105
IC2103
IC2104
IC2300
SA-VKX95GA/GS/EE MAIN P.C.B. ASS'Y
IC2107
IC2108
IC2300
IC2300
IC3001
IC2300
IC2300
IC3001
