Panasonic SB-WA310 - Page 157

R3007
2.2K
R3008
3.3K
C3039
47
C3037
6.3V330P
MDQ(22)
MDQ(25)
MDQ(23)
MDQ(24)
R3004
1.5K
R3005
1.2K
C3020 0.1
C3022
0.1
C3023
0.1
R3006
1.2K
K3003
0
CP3017
CP3016
CP3015
CP3014
CP3013
CP3012
CP3011
CP3010
CP3009
CP3008
CP3007
CP3006
CP3005
CP3004
CP3003
CP3002
RA3005
(82 x 4)
L3001
G1C100K00020
C3051
22P
R3009 100
RA3053
(100 x 2)
R3052 56
R3051 100
RA3051
(100 x 2)
R3102
2.7K
R3101
15K
K3101
0
R3106
62
R3107
15
K3106
0
R3112
15
R3111
62
R3113
33
C3111
0.1
R3114
1K
Q3111
R3116
62
R3117
13
C3116
0.1
R3118
1K
Q3116
R3121
100
R3122
16
C3121
0.1
R3123
1K
Q3121
C3110
6.3V100P
L3091
G1C100K00020
CP3018
CP3019
CP3020
CP3021
CP3022
CP3023
CP3024
Q3111,Q3116,Q3121
2SB1218ARL
AMPLIFIER
AUDIODIGITAL AD
AD
AD
AD
AD
AD
AD
AD
AOUT0
AOUT1
AOUT2
DMIXOUT
SRCK
LRCK
EXTCLK
VDY/PY/G
VDCB/PB/B
VDCR/PR/R
VDV+5V
FEP/SODC/VDA+5V
VDC
VDY
DVD MODULE (2) (AVDEC) CIRCUIT
SCHEMATIC DIAGRAM-9
: DVD AUDIO SIGNAL
: DVD VIDEO SIGNAL
: +B SIGNAL LINE
