16.9. Removing the Cassette Tape Manually
When electrical system failure occurs and a loaded cassette tape is stuck in the unit, follow the
instruction below to remove it.
16.9.1. Removal by Compulsory Loading
(Available when service mode is on even when the power cannot be turned off.)
1. Press and hold down the "FF" and "EJECT" buttons at least three
seconds then adjust the service number until appears as "7".
2. Press the "STOP" button to unload. / (Carefully check for tape
slack)
16.9.2. Removal by Use of Battery to Rotate Loading Motor
1. Unplug the power outlet, and remove the top panel and the front
panel.
2. Use a mechanism drive jig (or three AA-size batteries connected in
series) in order to supply 4.5V and to rotate the loading motor.
70
