Panasonic SB-WA310 - Component Parts List

Ref. No. Part No. Part Name & Description Remarks
53
RMN0575 PCB SPACER
[M]
54
RMR1359-W PCB SPACER
[M]
24.4. Component Parts List
Ref. No. Part No. Part Name & Description Remarks
PRINTED CIRCUIT BOARD
REP3406A-1N
DVD MODULE (1) P.C.B. (SIDE: A) [M](RTL)
REP3406A-1N DVD MODULE (1) P.C.B. (SIDE: B) [M](RTL)
REPX0371A
DVD MODULE (2) P.C.B. (SIDE: A) [M](RTL)
REPX0371A
DVD MODULE (2) P.C.B. (SIDE: B) [M](RTL)
VEP06F25A-1 MAIN P.C.B. [M](RTL)
VEP03G36A DSP P.C.B. (SIDE: A) [M](RTL)
VEP03G36A DSP P.C.B. (SIDE: B) [M](RTL)
VEP7A58A REGULATOR P.C.B. [M](RTL)
VEP7A59A TUNER P.C.B. [M](RTL)
VEP01930A POWER P.C.B. [M](RTL)
VEP03G37A INPUT P.C.B. [M](RTL)
VEP9127A INPUT SELECTOR (1) P.C.B. [M](RTL)
VEP9128A INPUT SELECTOR (2) P.C.B. [M](RTL)
VEP02578A VCR DECK P.C.B.
[M](RTL)
INTEGRATED CIRCUITS
IC101 C2CBGF000166 IC MICRO CONTROLLER [M]
IC102 C0JBAS000008 IC ANALOG SWITCH [M]
IC201 C2HBZC000013 IC DSP [M]
IC201
C1AB00001472
IC CAPSTAN DRIVE [M]
IC302 KIA4558FEL IC DUAL OP-AMP [M]
IC371 M62444FPE1 IC 4CH VOLUME [M]
IC372 C0JBAR000292 IC ANALOG SW [M]
IC401 C0AABB000055 IC AMP [M]
IC701 C0ABCB000040 IC QUAD OP AMP [M]
IC751 M62456FPE1 IC BLT [M]
IC1200 C0DAEJC00003 IC SHUNT REGULATOR [M]
IC1511 B3NAA0000049 IC T-REEL SENSOR [M]
IC1512 B3NAA0000049 IC S-REEL SENSOR [M]
IC2001 MN103S26EGA IC SODC [M]
IC2101 C0JBAS000116 IC LOGIC [M]
IC2501 C0GBG0000033
IC MOTOR DRIVE
[M]
IC2501 C1AB00001479 IC CYL DRIVE [M]
IC2502 C0DBZJG00005 IC REGULATOR [M]
IC3001 C1AB00001506 IC AV DECORDER [M]
IC3001 MN6775511 IC AV DEC [M]
IC3061 C3ABPG000068 IC 64 SDRAM [M]
IC3062 C3ABPG000068 IC 64 SDRAM [M]
IC3201 C1AB00001192 IC SWITCHING [M]
IC4211 C0FBBK000036 IC AUDIO DAC [M]
IC4501 AN3663FBP-AV IC AUDIO [M]
IC5201 AN22030A-VT IC FEP [M]
IC6001 C2CBHF000262 IC VIDEO SYSCON [M]
IC6201 C0EBH0000172 IC RESET [M]
99
