Panasonic SC-HTB500 User Manual

17
Operating Instructions
Specifications
Dimensions (WkHkD):
This unit
(Without wall mount bracket)
1029 mmk108 mmk58 mm
(With wall mount bracket)
1029 mmk108 mmk80 mm
Active subwoofer
250 mmk323 mmk356 mm
Digital transmitter
43.5 mmk37.3 mmk8.2 mm
Mass:
This unit
(Without wall mount bracket)
Approx. 2.8 kg
(With wall mount bracket)
Approx. 2.9 kg
Active subwoofer
Approx. 6.7 kg
Digital transmitter
Approx. 0.0095 kg
Operating temperature range:
0
o
C to r40
o
C
Operating humidity range:
20 % to 80 % RH (no condensation)
RMS Output Power
Front ch:
60 W per channel (4 ≠), 1 kHz, 10 % THD
Subwoofer ch:
120 W per channel (8 ≠), 100 Hz, 10 % THD
Total RMS Dolby Digital mode power: 240 W
(Except Continental Europe, Australia and
New Zealand)
PMPO Output Power: 2100 W
FRONT SPEAKERS (BUILT-IN)
Type: 1 way, 1 speaker system (Bass Reflex)
Full range: 6.5 cm Cone typek2
ACTIVE SUBWOOFER
Type: 1 way, 1 speaker system (Kelton type)
Woofer: 16 cm Cone type
Passive radiator: 25 cm
Output sound pressure: 78 dB/W (1 m)
Frequency range: 35 Hz to 180 Hz (j16 dB)
40 Hz to 160 Hz (j10 dB)
HDMI
This unit supports “HDAVI Control 5” function.
HDMI input
Input connector: Type A (19 pin)
HDMI AV output
Output connector: Type A (19 pin)
Digital Audio Input (TV only)
Optical digital input: Optical terminal
Sampling frequency: 32 kHz, 44.1 kHz, 48 kHz
Audio Format: LPCM, Dolby Digital
IR Blaster
Terminal 1: 3.5 mm jack
Wireless module
Frequency range: 2.4 GHz to 2.4835 GHz
Number of channels: 3

1 Specifications are subject to change without notice.
Mass and dimensions are approximate.
2 Total harmonic distortion is measured by a digital spectrum
analyzer.
GENERAL
Power consumption:
This unit:
(Continental Europe, Australia and New
Zealand) 26 W
(Others) 29 W
Active subwoofer: 25 W
Digital transmitter: 1.2 W
Power consumption in standby mode:
This unit: Approx. 0.2 W
Power consumption in off mode:
Active subwoofer: Approx. 0.4 W
Power supply:
(Continental Europe, Australia and New
Zealand)
AC 220 V to 240 V, 50 Hz
(Others)
This unit: AC 110 V to 127 V/220 V to 240 V,
50/60 Hz
Active subwoofer: AC 110 V to 240 V,
50/60 Hz
AMPLIFIER SECTION
SPEAKER SECTION
TERMINAL SECTION
WIRELESS SECTION
SCHTB500EGGNGS_RQTX1185-B.book Page 17 Wednesday, July 7, 2010 5:18 PM

Panasonic SC-HTB500 Specifications

General

Audio decoders	Dolby Digital, Dolby Pro Logic II, DTS
RMS rated power	240 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Impedance	4 Ω
Tweeter diameter	65 mm
Soundbar speaker RMS power	120 W
Tweeter diameter (imperial)	2.5 \
Total Harmonic Distortion (THD)	10 %
Subwoofer connectivity	Wireless
Receiver included	No
Product color	Black
Recommended usage	Home theatre
Consumer Electronics Control (CEC)	VIERA Link
Apple docking compatibility	Not supported
Soundbar dimensions (WxDxH)	1029 x 58 x 108 mm
Subwoofer dimensions (WxDxH)	250 x 356 x 323 mm
HDMI in	1
Connectivity technology	Wired
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	29 W

Weight and Dimensions

Soundbar weight	2800 g
Subwoofer weight	6700 g
