Panasonic SC-PM10 User Manual

RQT6682
2
Before use
Dear customer
Thank you for purchasing this product.
For optimum performance and safety, please read these
instructions carefully.
These operating instructions are applicable to the following
system.
System SC-PM10
Main unit SA-PM10
Speakers SB-PM10
Inside of product
Tuotteen sisällä
Produktets innside
Table of contents
Before use
Supplied accessories ................................................. 3
Safety precautions ...................................................... 3
Caution for AC Mains Lead ........................................ 4
The remote control ..................................................... 5
Placement of speakers ............................................... 5
Connections ................................................................ 6
Front panel controls ................................................... 8
Setting the time ........................................................... 9
Convenient Functions ................................................ 9
Turning the demo function off ................................... 9
Listening operations
The radio: manual tuning .......................................... 10
The radio: preset tuning ............................................ 11
CDs ............................................................................... 12
Cassette tapes ............................................................. 15
Recording operations
Before recording ......................................................... 16
Recording the radio .................................................... 16
Recording CDs ............................................................ 17
Timers and others
Sound Quality .............................................................. 19
Using the timers .......................................................... 20
Reference
Troubleshooting guide ............................................... 22
Technical specifications ............................................ 23
Maintenance ................................................................ 23
THIS UNIT IS INTENDED FOR USE IN MODERATE
CLIMATES.
TÄMÄ LAITE ON TARKOITETTU KÄYTETTÄVÄKSI
LEUDOSSA ILMASTOSSA.
DETTE APPARATET ER BEREGNET TIL BRUK
UNDER MODERATE KLIMAFORHOLD.
Side of product
(For Europe, Australia and New Zealand)
This product may receive radio interference caused by mo-
bile telephones during use. If such interference is apparent,
please increase separation between the product and the
mobile telephone.
THIS UNIT IS INTENDED FOR USE IN TROPICAL
CLIMATES.
(For others)
RQT6682(2-10)new 1/9/03, 9:32 AM2

Panasonic SC-PM10 Specifications

Amplifier Section

FTC power output	14W per channel (6 Ω)
RMS power output	15W per channel (6 Ω)
Output impedance - Headphone	16-32 Ω

FM Tuner Section

Frequency range (200 kHz steps)	87.9–107.9 MHz
Frequency range (100 kHz steps)	87.5–108.0 MHz
Sensitivity	2.0 µV (IHF)

AM Tuner Section

Frequency range	520 – 1710 kHz (10 kHz steps)
Sensitivity S/N 20 dB (at 1000 kHz)	560 µV/m

Cassette Deck Section

Tape speed	4.8 cm/s
Wow and flutter	0.15% (WRMS)
Fast forward and rewind time	Approx. 120 seconds with C-60 cassette tape

CD Section

Sampling frequency	44.1 kHz
Beam source/wavelength	Semiconductor laser/780 nm
Wow and flutter	Below measurable limit

Speaker Section

Speaker full range	10 cm (4˝) cone type
Tweeter	6 cm (2 [3]/8˝) cone type
Dimensions (WxHxD)	140 x 225 x 228 mm

General

Power supply	AC 120 V, 60 Hz
Power consumption	38 W
Dimensions (WxHxD)	165 x 228 x 313 mm
