Before use
Front panel controls
A Main unit
1
Headphone jack (PHONES) ..................................... 19
2 Cassette lid
3 Cassette open button (OPEN c) ............................ 15
4 Display
5 Tuner/band select button (TUNER/BAND) ............. 10
6 Remote control signal sensor
7 AC supply indicator (AC IN)
This indicator lights when the unit is connected to the AC
mains supply.
8 Standby/on switch ( )
Press to switch the unit from on to standby mode or vice
versa. In standby mode, the unit is still consuming a
small amount of power.
9 Stop, demonstration, TAPE/CD mode select button
(STOP L, –DEMO) .................................... 9, 12, 15, 16
Ä Recording start/pause button ([REC/ J) ......... 16, 17
Å CD skip/search, tape fast-forward/rewind, tune/
preset channel select, time adjust buttons
( g/REW/
44
44
4,
33
33
3 /FF/f ) .. 9, 10, 11, 12, 14, 15, 18, 20
Ç CD play/pause button (CD -/ J) ............................. 12
É Preset EQ select button (PRESET EQ) .................. 19
Ñ Sound virtualizer button
(SOUND VIRTUALIZER) ........................................... 19
Ö Volume control (VOLUME DOWN, UP)....... 10, 12, 15
Ü Cassette play button (TAPE 2) .............................. 15
á CD tray open/close button (OPEN/CLOSE c) ....... 12
à CD tray
B Remote Control
Buttons such as 8 function in exactly same way as the
buttons on the main unit.
â Sleep timer button (SLEEP) .................................... 21
ä CD program/clear, tuner preset button
(PROGRAM/–CLEAR) ........................................ 11, 14
ã CD play mode select button (CD PLAY MODE)..... 13
å CD recording mode button (CD REC MODE) ........ 18
ç FM mode, BP button (FM MODE)...................... 10, 16
é Tuning mode select button (TUNE MODE) ...... 10, 11
è Muting button (MUTING) ......................................... 9
ê Play timer/recording timer button
(
˚˚
˚˚
˚PLAY/REC) ........................................................... 20
ë Clock/timer button (CLOCK/TIMER) ............. 9, 20, 21
í Numeric buttons ................................................ 11, 13
ì Stop, TAPE/CD mode select button (STOP L) ...... 13
î Treble button (TREBLE) .......................................... 19
ï Bass button (BASS) ................................................. 19
ñ Dimmer button (DIMMER) ....................................... 9
ó Display button (DISPLAY) ................................... 9, 10
REC
REW
FF
DOWN UP
OPEN CLOSE
TAPE
TUNER BAND
STOP
CD
VOLUME
AC IN
DEMO
PRESET EQVIRTUALIZER
SOUND
PHONES
OPEN
%
&
(
)
#
$
~
5
7
8
!
"
9
4
6
3
1
2
A
B
123
45
6
789
0
10
VOL VOL
REW
FF FM MODEFM MODE
DIMMERDISPLAY
MUTING
BASS
TREBLE
PLAY
SLEEP
TIMER
CLOCK
REC
EQ
VIRTUALIZER
SOUND
PRESET
TUNE MODETUNE MODE
CD REC
MODE
CD PLAY
MODE
PROGRAM/
CLEAR
TAPE
TUNER
BAND
CD
STOP
<
=
>
?
@
[
\
]
(
"
;
:
.
-
,
+
/
$
%
&
5
#
8
RQT6682(2-10).P65 3/24/05, 12:03 PM8

Panasonic SC-PM10 Specifications

Amplifier Section

FTC power output	14W per channel (6 Ω)
RMS power output	15W per channel (6 Ω)
Output impedance - Headphone	16-32 Ω

FM Tuner Section

Frequency range (200 kHz steps)	87.9–107.9 MHz
Frequency range (100 kHz steps)	87.5–108.0 MHz
Sensitivity	2.0 µV (IHF)

AM Tuner Section

Frequency range	520 – 1710 kHz (10 kHz steps)
Sensitivity S/N 20 dB (at 1000 kHz)	560 µV/m

Cassette Deck Section

Tape speed	4.8 cm/s
Wow and flutter	0.15% (WRMS)
Fast forward and rewind time	Approx. 120 seconds with C-60 cassette tape

CD Section

Sampling frequency	44.1 kHz
Beam source/wavelength	Semiconductor laser/780 nm
Wow and flutter	Below measurable limit

Speaker Section

Speaker full range	10 cm (4˝) cone type
Tweeter	6 cm (2 [3]/8˝) cone type
Dimensions (WxHxD)	140 x 225 x 228 mm

General

Power supply	AC 120 V, 60 Hz
Power consumption	38 W
Dimensions (WxHxD)	165 x 228 x 313 mm
