38
RQT7509
Reference
Specifications
AMPLIFIER SECTION
RMS Output Power Stereo mode (Both channel driven)
10% total harmonic distortion
1
kHz (Low channel) 35
W per channel (6
Ω)
8
kHz (High channel) 35
W per channel (6
Ω)
Total RMS Stereo mode power 140
W
FTC Output Power Stereo mode (Both channel driven)
10% total harmonic distortion
60
Hz – 3 kHz (Low channel) 30
W per channel (6
Ω)
3
kHz – 16 kHz (High channel) 30
W per channel (6
Ω)
Total FTC Stereo mode power 60 W per channel
Phone jack
Terminal Stereo, 3.5 mm (
1
/
8
”) jack
FM TUNER SECTION
Frequency range 87.9 – 107.9
MHz
(200 kHz step)
87.5 – 108.0
MHz
(100 kHz step)
Sensitivity 2.5
µV
(IHF)
S/N 26 dB 2.2
µV
Antenna terminals 75
Ω (unbalance)
Preset stations 15
AM TUNER SECTION
Frequency range 520 – 1710
kHz
(10 kHz steps)
Sensitivity
S/N 20 dB at 1000 kHz 560
µV/m
Preset stations 15
CASSETTE DECK SECTION
Track system 4-track, 2-channel
Heads
Record/playback Solid permalloy head
Erasure Double gap ferrite head
Motor DC servo motor
Recording system AC bias 100 kHz
AC erase 100 kHz
Tape speed 4.8 cm/s (1–7/8 ips)
Overall frequency response (+3, –6 dB) at DECK OUT
Normal (TYPE I) 35 Hz
–
14 kHz
S/N ratio 50 dB (A weighted)
Wow and flutter 0.18% (WRMS)
Fast forward and rewind time Approx. 120 seconds with
C-60 cassette tape
DISC SECTION
Disc played [8 cm (3”) or 12 cm (5”)]
(1) DVD-RAM (DVD-VR compatible, JPEG formatted disc)
(2) DVD-Audio
(3) DVD-Video
(4) DVD-R (DVD-Video compatible)
(5) CD-Audio (CD-DA)
(6) Video CD
(7) SVCD (Conforming to IEC62107)
(8) CD-R/CD-RW
(CD-DA, Video-CD, SVCD, MP3, WMA, JPEG formatted
disc)
(9) MP3/WMA
\
•
Compatible compression rate:
MP3: between 32 kbps and 320 kbps
WMA: between 48 kbps and 320 kbps
(10) JPEG
\
•
Exif Ver 2.1 JPEG Baseline files
•
Picture resolution:
between 320x240 and 6144x4096 pixels
(Sub sampling is 4:2:2 or 4:2:0)
(11) HighMAT Level 2 (Audio and Image)
\
The total combined maximum number of recognizable audio
and picture contents and groups: 4000 audio and picture
contents and 400 groups.
Video system NTSC
Composite video output
Output level 1
Vp-p (75
Ω)
Terminal Pin jack (1 system)
S-VIDEO output
Y output level 1
Vp-p (75
Ω)
C output level 0.286
Vp-p (75
Ω) (NTSC)
Terminal S terminal (1 system)
Component video output (480P/480I)
Y output level 1
Vp-p (75
Ω)
P
B output level 0.7
Vp-p (75
Ω)
P
R output level 0.7
Vp-p (75
Ω)
Terminal Pin jack (Y:green, P
B: blue, PR:red)
(1 system)
Audio output
Number of channels 2
Digital audio output
Optical digital output Optical terminal
Pick up
Wavelength
DVD 662 nm
CD 785 nm
Laser power
For U.S.A. CLASS IIa/CLASS I
For Canada and Latin America CLASS 2/CLASS 3a
SPEAKER SECTION
Type 3 way, 3 speaker system (Bass reflex)
Speaker units
Woofer 10 cm (4”) cone type
Tweeter 6 cm (2
3
/
8
”) ring shaped dome type
Super tweeter Piezo type
Impedance
High 6
Ω
Low 6
Ω
Input power (IEC) High 35 W (Max)
Low 35 W (Max)
Output sound pressure level 80 dB/W (1.0 m)
Crossover frequency 2.6 kHz, 10 kHz
Frequency range 42 Hz–50 kHz (–16 dB)
52 Hz–45 kHz (–10 dB)
Dimensions (WxHxD) 145 x 250 x 274 mm
(5
23
/
32
” x 9
27
/
32
” x 10
25
/
32
”)
Mass 2.6 kg (5.7 lbs)
GENERAL
Power supply AC 120V, 60 Hz
Power consumption 130 W
Dimensions (WxHxD) 174.6 x 251 x 376 mm
(6
7
/
8
” x 9
7
/
8
” x 14
13
/
16
”)
Mass 5.7 kg (12.6 lbs)
Operating temperature range + 5°C to + 35°C (+41°F to +95°F)
Operating humidity range 5% to 90% RH (no condensation)
Power consumption in standby mode 0.5 W
Note
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by digital spectrum
analyzer.
RQT7509_38 2/20/04, 3:01 PM38
