47
Applicable input signals
*
Mark: Applicable input signal
Signal name
Horizontal frequency
(kHz)
Vertical frequency
(Hz)
COMPONENT /
RGB IN / PC IN
(Dot clock (MHz))
DVI-D IN
(Dot clock (MHz))
HDMI
1 525 (480) / 60i 15.73 59.94 * (13.5) * (27.0)
*
2 525 (480) / 60p 31.47 59.94 * (27.0)
∗4 * (27.0)
*
3 625 (575) / 50i 15.63 50.00 * (13.5)
4 625 (576) / 50i 15.63 50.00 * (27.0)
*
5 625 (575) / 50p 31.25 50.00 * (27.0)
6 625 (576) / 50p 31.25 50.00 * (27.0)
*
7 750 (720) / 60p 45.00 60.00 * (74.25) * (74.25)
*
8 750 (720) / 50p 37.50 50.00 * (74.25) * (74.25)
*
9 1,125 (1,080) / 60p 67.50 60.00 * (148.5)
∗1 * (148.5)
*
10 1,125 (1,080) / 60i 33.75 60.00 * (74.25)
∗1 * (74.25)
*
11 1,125 (1,080) / 50p 56.26 50.00 * (148.5)
∗1 * (148.5)
*
12 1,125 (1,080) / 50i 28.13 50.00 * (74.25)
∗1 * (74.25)
*
13 1,125 (1,080) / 24sF 27.00 48.00 * (74.25)
∗2
14 1,125 (1,080) / 30p 33.75 30.00 * (74.25)
∗1 * (74.25)
15 1,125 (1,080) / 25p 28.13 25.00 * (74.25)
∗1 * (74.25)
16 1,125 (1,080) / 24p 27.00 24.00 * (74.25)
∗1 * (74.25)
*
17 640 × 400 @70 Hz 31.46 70.07 * (25.17)
18 640 × 480 @60 Hz 31.47 59.94 * (25.18) ∗5 * (25.18)
*
19 640 × 480 @72 Hz 37.86 72.81 * (31.5)
20 640 × 480 @75 Hz 37.50 75.00 * (31.5)
21 640 × 480 @85 Hz 43.27 85.01 * (36.0)
22 800 × 600 @56 Hz 35.16 56.25 * (36.0)
23 800 × 600 @60 Hz 37.88 60.32 * (40.0) * (40.0)
*
24 800 × 600 @72 Hz 48.08 72.19 * (50.0)
25 800 × 600 @75 Hz 46.88 75.00 * (49.5)
26 800 × 600 @85 Hz 53.67 85.06 * (56.25)
27 852 × 480 @60 Hz 31.47 59.94 * (33.54)
∗5*
(34.24)
*
28 1,024 × 768 @50 Hz 39.55 50.00 * (51.89)
*
29 1,024 × 768 @60 Hz 48.36 60.00 * (65.0) * (65.0)
*
30 1,024 × 768 @70 Hz 56.48 70.07 * (75.0)
31 1,024 × 768 @75 Hz 60.02 75.03 * (78.75)
32 1,024 × 768 @85 Hz 68.68 85.00 * (94.5)
33 1,066 × 600 @60 Hz 37.64 59.94 * (53.0) * (53.0)
*
34 1,152 × 864 @60 Hz 53.70 60.00 * (81.62)
*
35 1,152 × 864 @75 Hz 67.50 75.00 * (108.0)
36 1,280 × 768 @60 Hz 47.70 60.00 * (80.14)
37 1,280 × 960 @60 Hz 60.00 60.00 * (108.0)
38 1,280 × 960 @85 Hz 85.94 85.00 * (148.5)
39 1,280 × 1,024 @60 Hz 63.98 60.02 * (108.0) * (108.0)
*
40 1,280 × 1,024 @75 Hz 79.98 75.03 * (135.0)
41 1,280 × 1,024 @85 Hz 91.15 85.02 * (157.5)
42 1,366 × 768 @50 Hz 39.55 50.00 * (69.92)
*
43 1,366 × 768 @60 Hz 48.36 60.00 * (86.71) * (87.44)
*
44 1,400 × 1,050 @60 Hz 65.22 60.00 * (122.61)
*
45 1,600 × 1,200 @60 Hz 75.00 60.00 * (162.0) * (162.0)
*
46 1,600 × 1,200 @65 Hz 81.25 65.00 * (175.5)
47 1,920 × 1,080 @60 Hz 67.50 60.00 * (148.5)
∗3 * (148.5)
*
48 1,920 × 1,200 @60 Hz 74.04 59.95 * (154.0)
*
49 Macintosh13” (640 × 480) 35.00 66.67 * (30.24)
50 Macintosh16” (832 × 624) 49.72 74.54 * (57.28)
51 Macintosh21” (1,152 × 870) 68.68 75.06 * (100.0)
∗1:
Based on SMPTE 274M standard.
∗2:
Based on SMPTE RP211 standard.
∗3:
The input signal is recognized as 1,125 (1,080) / 60p.
∗4:
When selected the RGB format and 525p signal input to the PC IN terminal, it is recognized as VGA 60Hz signal.
∗5:
When inputted VGA 60Hz format signal from the other than PC IN terminal, it is recognized as 525p signal.
Note: Signals without above specifi cation may not be displayed properly.
