Preset Signals
This unit can display the video signals shown in the table below.
■ Video signal
Corresponding signal Resolution (Dot)
Scanning frequency
Dot clock
frequency
(MHz)
Format
*
3
Horizontal
(kHz)
Vertical
(Hz)
525i(480i) 720 x 480i 15.73 59.94 13.50 R/Y
625i(576i) 720 x 576i 15.63 50.00 13.50 R/Y
525i(480i) 720(1 440) x 480i
*
2
15.73 59.94 27.00 D/H/DP/DL
625i(576i) 720(1 440) x 576i
*
2
15.63 50.00 27.00 D/H/DP/DL
525p(480p) 720 x 480 31.47 59.94 27.00 R/Y/D/H/DP/DL
625p(576p) 720 x 576 31.25 50.00 27.00 R/Y/D/H/DP/DL
750(720)/60p 1 280 x 720 45.00 60.00 47.25 R/Y/D/H/DP/DL
750(720)/50p 1 280 x 720 37.50 50.00 74.25 R/Y/D/H/DP/DL
1125(1080)/60i
*
1
1 920 x 1 080i 33.75 60.00 74.25 R/Y/D/H/DP/DL
1125(1080)/50i 1 920 x 1 080i 28.13 60.00 74.25 R/Y/D/H/DP/DL
1125(1080)/24p 1 920 x 1 080 27.00 24.00 74.25 R/Y/D/H/DP/DL
1125(1080)/24PsF 1 920 x 1 080i 27.00 48.00 74.25 R/Y
1125(1080)/25p 1 920 x 1 080 28.13 25.00 74.25 R/Y/D/H/DP/DL
1125(1080)/30p 1 920 x 1 080 33.75 30.00 74.25 R/Y/D/H/DP/DL
1125(1080)/60p 1 920 x 1 080 67.50 60.00 148.50 R/Y/D/H/DP/DL
1125(1080)/50p 1 920 x 1 080 56.25 50.00 148.50 R/Y/D/H/DP/DL
■ PC signal
Corresponding signal Resolution (Dot)
Scanning frequency
Dot clock
frequency
(MHz)
Format
*
3
Horizontal
(kHz)
Vertical
(Hz)
VESA400 640 x 400
31.47 70.09 25.18 R/Y/D/H/DP/DL
37.86 85.08 31.50 R/Y/D/H/DP/DL
VGA 640 x 480
31.47 59.94 25.18 R/Y/D/H/DP/DL
35.00 66.67 30.24 R/Y/D/H/DP/DL
37.86 72.81 31.50 R/Y/D/H/DP/DL
37.50 75.00 31.50 R/Y/D/H/DP/DL
43.27 85.01 36.00 R/Y/D/H/DP/DL
SVGA 800 x 600
35.16 56.25 36.00 R/Y/D/H/DP/DL
37.88 60.32 40.00 R/Y/D/H/DP/DL
48.08 72.19 50.00 R/Y/D/H/DP/DL
46.88 75.00 49.50 R/Y/D/H/DP/DL
53.67 85.06 56.25 R/Y/D/H/DP/DL
MAC16 832 x 624 49.72 74.55 57.28 R/Y/D/H/DP/DL
852 x 480 852 x 480 31.47 59.94 34.24 D/H/DP/DL
XGA 1 024 x 768
39.55 50.00 51.89 D/H/DP/DL
48.36 60.00 65.00 R/Y/D/H/DP/DL
56.48 70.07 75.00 R/Y/D/H/DP/DL
60.02 75.03 78.75 R/Y/D/H/DP/DL
65.55 81.63 86.00 R/Y/D/H/DP/DL
68.68 85.00 94.50 R/Y/D/H/DP/DL
WSVGA 1 066 x 600 37.64 59.94 53.00 D/H/DP/DL
MXGA 1 152 x 864
53.70 60.00 81.62 D/H/DP/DL
63.99 70.02 94.20 R/Y/D/H/DP/DL
67.50 75.00 108.00 R/Y/D/H/DP/DL
77.09 85.00 119.65 R/Y/D/H/DP/DL
MAC21 1 152 x 870 68.68 75.06 100.00 R/Y/D/H/DP/DL
1280 x 720 1 280 x 720 44.76 60.00 74.48 R/Y/D/H/DP/DL
1280 x 768 1 280 x 768
39.55 49.94 65.18 R/Y/D/H/DP/DL
47.70 60.00 80.14 R/Y/D/H/DP/DL
47.78 59.87 79.50 R/Y/D/H/DP/DL
1280 x 800 1 280 x 800
41.20 50.00 68.56 R/Y/D/H/DP/DL
49.31 59.91 71.00 R/Y/D/H/DP/DL
49.70 59.81 83.50 R/Y/D/H/DP/DL
MSXGA 1 280 x 960
60.00 60.00 108.00 R/Y/D/H/DP/DL
85.94 85.00 148.50 R/Y
