Panasonic TH-55VF2W - Selecting the Input Signal; Recall

35
English
Selecting the input signal
Select the signals input to the unit.
Press <INPUT> or <INPUT (Unit)>.
Unit
MENU ENTERINPUT
Switches input every time the buttons are pressed.
PC
16:9
[HDMI]→[DisplayPort]→[DIGITAL LINK]→[DVI-D1]
→[DVI-D2]→[PC]→[USB]
[HDMI]:
HDMI terminal, HDMI input
[DisplayPort]:
DisplayPort terminal, DisplayPort input
[DIGITAL LINK]:
DIGITAL LINK terminal, DIGITAL LINK input
[DVI-D1]:
DVI-D IN 1 terminal, DVI-D input
[DVI-D2]:
DVI-D IN 2 terminal, DVI-D input
[PC]:
PC IN terminal, PC input
[USB]:
USB terminal, USB input
Note
●
Displays the signal name as set in [Input label]. (see
page 64)
●
Input will not be switched unless [Input lock] is set to
[Off]. (see page 77)
●
Image retention (image lag) may occur on the liquid
crystal panel when a still picture is kept on the panel
for an extended period. To prevent such a problem,
using the screensaver and wobbling is recommended.
(see page 63, 66)
RECALL
It is possible to check the setting status of input label,
picture mode, etc.
Press <RECALL>.
Current setting status will be displayed.
10:00
1
2
3
4
5
6
7
8
PC
16:9
Backup mode OK
AUDIO1 IN
Memory name: MEMORY2
Off timer
90 min
MDB:Parent
1 Input label
2 Aspect mode (see page 37)
3 Backup input change (see page 60, 61)
4 Audio input (see page 76)
5 Profile name (see page 49)
6 Multi dynamic backlight (see page 52)
7 Off timer remaining time (see page 36)
8 Clock / Mute (see page 36)
●
When there is no video signal to the selected input,
[No signal] is displayed for about 30 seconds at the
end.
●
When a USB memory is not connected to the USB
terminal at the time of using the USB input, [No
external media] is displayed for about 30 seconds.
Even when a USB memory is connected, if it does not
contain any playable file, [No play file] is displayed at
all times.
●
To display the clock, set [Date and time], and then set
[Clock display] to [On]. (see page 67, 78)
