Preparations / 配件及準備
Installing the Alkaline Ionizer (continued)
1
After completing the preparations,
connect the water supply hose.
2
Secure the water supply
hose
(using the hose strap)
3
Screw in the outlet pipe until it is secured firmly.
ODo not use any tools for this job (since the pipe may be damaged).
OEnsure that the gasket is not twisted (since this may cause the water to leak).
ODo not lift the main unit by taking hold of the outlet pipe (otherwise damage may result).
❶Remove the hose fastening nut from the bypass
selector, and pass the hose through the nut.
❸Tighten up the hose fastening nut securely.
ODo not use any tools for this job (since the hose
fastening nut may be damaged).
❷Insert the water supply
hose into the bypass
selector as far as it will go.
Caution label
Affix the label on
the main unit or at
an easily viewable
location near the
main unit.
Gasket
OK NG
Gap
4
Secure the drain hose using the suction disc.
OSecure the hoses so that they will not move out of place.
Installation position
Bottom of main unit
Drain hose
Main spout
Height difference
The tip of the drain hose must be below the level of the bottom of the main unit and the difference
in height between the main spout and tip of the drain hose must be greater than 10 cm and less
than 50 cm (so that the appropriate pH level (ion concentration) is achieved).
5
Connect the power plug to the power outlet (AC 220 V – 240 V).
OThe buzzer beeps three times and the water quality indicator lamp lights up at purified water.
OThe Alkaline Ionizer’s power consumption is 1 W even in the standby status.
Important
OAfter installing the Alkaline Ionizer, run purified water through the unit for about 3 or
4 minutes to expel the air inside the main unit.
OThe power plug is normally kept connected to the power outlet (to keep the automatic
electrode cleaning function working).
Note
OIf the hose is too long, it is recommended that you cut it to the proper length (cut it straight down).
OImmediately after the Alkaline Ionizer has been installed, the water quality indicator lamp blinks for
about 10 seconds – 40 seconds when water is run through the Alkaline Ionizer.
P. 1 5
