Parts Location
A-BOARD (FOIL SIDE)
Q0900 D-1
Q0901 D-1
Q0903 C-5
Q0904 C-5
Q0905 C-5
Q2001 C-2
Q2022 G-2
Q2023 D-3
Q2901 C-2
Q2902 D-2
Q2903 C-1
Q2904 C-3
Q3001 G-2
Q3002 F-2
Q3303 F-2
Q4500 F-3
Q4501 E-3
Q4533 E-4
Q4534 F-4
Q8401 D-6
Q8402 D-6
Q8851 F-4
Q8852 E-4
Q9000 H-5
Q9001 H-5
Q9002 G-6
Q9003 G-1
Q9004 G-6
TRANSISTOR
IC1100 E-4
IC2008 E-4
IC2801 D-6
IC2901 C-3
IC3003 F-2
IC4511 F-4
IC4512 E-3
IC4513 E-4
IC5480 C-5
IC5600 C-5
IC5601 D-5
IC8004 G-4
IC8301 D-2
IC8302 D-2
IC8401 F-6
IC8403 E-5
IC8404 E-5
IC8405 E-5
IC8408 D-5
IC8554 F-5
IC8601 F-6
IC9001 G-6
IC9500 H-6
ICIC
Parts Location
Q2063 E-1
Q2064 D-1
Q2065 D-1
Q2066 D-1
Q2067 D-1
Q3000 D-2
Q3004 E-1
Q3005 E-1
Q4514 D-3
Q4515 D-3
Q4516 D-3
Q4517 D-3
Q4519 D-3
Q4520 G-4
Q4535 G-4
Q5480 E-1
Q5565 E-4
Q5600 G-5
Q5601 F-5
Q5602 F-5
Q5603 G-5
Q5606 F-5
Q5607 F-5
Q5608 E-5
Q8200 E-5
Q8850 D-5
Q8853 D-5
Q9301 B-5
Q9302 B-6
Q9807 C-3
TRANSISTOR
IC1000 G-4
IC1101 F-4
IC2301 C-2
IC2960 G-3
IC3001 C-3
IC4510 D-4
IC5401 F-6
IC5470 E-4
IC8001 C-5
IC8002 C-5
IC8003 C-5
IC8409 E-6
IC8410 F-5
IC8411 F-6
IC9003 C-6
IC9004 B-5
IC9303 C-3
IC9805 C-3
IC9806 D-4
IC9807 B-5
IC9808 C-3
IC9900 B-4
IC9901 C-4
ICIC
