Panasonic TY-WPR1 - Specifications

61English
■
Receiver
Model No. TY-WPR1 / TY-WPR1W
Product name WPS Receiver
Video output HDMI × 1 (HDCP1.4)
Output resolution 1920 x 1080/60p, 3840 x 2160/30p (max.)
Number of simultaneous
connections
32
Wireless communication
standard
IEEE802.11a/n/ac
Bluetooth(GFSK,π/4-DQPSK,8DPSK)
Data rate wireless 867 Mbps (max.)
Frequency band 5 GHz (5.150 GHz to 5.250 GHz)
Security WPA/WPA2/WPA3 (WPA3-Enterprise is not supported)
Reachable distance Up to 30 m (Locations with good visibility and radio wave conditions)
FUNCTION LED
White blinking Pairing in progress
White illumination Pairing complete
LAN terminal
RJ45 × 1
10BASE-T/100BASE-TX/1000BASE-T supported
USB terminal USB connector × 1, Type-A
Power supply DC 5 V/2 A
Dimensions (W × H × D) 120 mm × 26 mm × 81 mm / 4.71” × 1.03” × 3.19” (excluding antennas)
Mass Approx. 181 g / 0.4 lbs
Operating condition
Temperature: 0 °C to 35 °C (32 °F to 95 °F)
Humidity: 20 % to 80 % (no condensation)
Storage condition
Temperature: -20 °C to 60 °C (-4 °F to 140 °F)
Humidity: 20 % to 80 % (no condensation)
■
Receiver board
Model No. TY-SB01WP
Product name Wireless Presentation System Receiver Board
Video output HDMI × 1 (HDCP1.4)
Output resolution 1920 x 1080/60p, 3840 x 2160/30p (max.)
Number of simultaneous
connections
32
Wireless communication
standard
IEEE802.11a/n/ac
Bluetooth(GFSK,π/4-DQPSK,8DPSK)
Data rate wireless 867 Mbps (max.)
Frequency band 5 GHz (5.150 GHz to 5.250 GHz)
Security WPA/WPA2/WPA3 (WPA3-Enterprise is not supported)
Reachable distance
Up to 30 m
(Locations with good visibility and radio wave conditions)
FUNCTION LED
White blinking Pairing in progress
White illumination Pairing complete
LAN terminal
RJ45 × 1
10BASE-T/100BASE-TX/
1000BASE-T supported
USB terminal USB connector × 1, Type-A
Dimensions (W × H × D) 82 mm × 25 mm × 122 mm / 3.22” × 0.99” × 4.78” (excluding antennas)
Mass Approx. 125 g / 0.3 lbs
Specifications
