29
Important:
 • Ifopenwiringisconducted,besuretouseconduitsandrunthecablesinsidethetubestopro-
tect the cables from direct sunlight.
 • Whentheconduitisconnectedatthelateralorbottomposition,eitherofthearrowmarkson
the bracket shall be the top position.
 • Whentheconduitisconnectedfromthetop,thearrowmarkontheattachmentshallbeeither
of the right or left position.
<To connect conduit from the side or bottom>
<To connect conduit from the top>
 • Forinstallationonthewall,donotconnectthedehumidifyingdeviceattheuppersidetopre-
vent water from being stored in the dehumidifying device.
If water remains inside, the dehumidifying device cannot function properly.
 • Installationworkshallbesuchthatthereisnointrusionofwaterintothearchitecturethrough
the conduits having been joined.
Arrow mark
Connecting
conduit
FRONT
TOP
