Panasonic WV-S2131L - Parts and Functions

15
* This illustration represents WV-S2131L
Parts and functions
【Whole unit】
S2131L
S2111L
S2130
Built-in microphone port
Azimuth adjustment ring
Camera
Attachment plate (accessory)
Inner
cover
Dome cover
Enclosure
Tilting table
Panning table
External I/O terminal plug (accessory)
Camera xing screw
* This illustration represents WV-S2131L
Direction marker for installation (TOP⇧)
⿟Points up when installing to a wall.
Two-dimensional barcode
(Data Matrix): To our website*
1
*1 Depending on the scanning application used, the Data Matrix may not be able to be read
correctly. In this case, access the site by directly entering the following URL.
https://security.panasonic.com/support/qr_sp_select/
MONITOR OUT terminal
(factory shipment: NTSC monitor)
Screen display
top (TOP)
Power cord plug (accessory)
12 V DC power supply terminal
Terminals
⇩
【Camera body】
