13.4 Configure the VMD settings [VMD area]
Click the [VMD area] tab on the “Alarm” page. (®page 40, page 42)
The video motion detection areas can be set on this page.
Up to 4 areas can be set. When motion is detected in the set area, it will be regarded as an alarm.
IMPORTANT
• The alarm occurrence indication button (®page 9) will be displayed when motion is detected by the
VMD function.
• Depending on the network environment, notification may be delayed even when “Real time” is selected
for “Alarm status update mode” on the [Basic] tab of the “Basic” page. (®page 46)
• After configuring the VMD area, the VMD area may move out of alignment when the JPEG/H.264
“Image capture mode” setting is changed. Make sure to check the setting after changing the “Image
capture mode” setting.
• After configuring the VMD area, the VMD area may move out of alignment when “Extra zoom” is
configured. Make sure to check the setting after changing the “Extra zoom” setting.
• The motion detection function is not the dedicated function to prevent thefts, fires, etc. We are not
responsible for any accidents or damages that may occur.
110 Operating Instructions
13 Configure the alarm settings [Alarm]
