Panasonic WV-SW395

Connection example
(Refer to page 22 for how to connect the cables.)
When connecting with a PC directly
<Required cable>
LAN cable (category 5e or better, cross, STP*)
* PAL model only
To the power supply
(24 V AC)
LAN cable
(category 5e or better, cross, STP*)
PC
Powered speaker (option)
Plug-in power type
microphone (option)
RJ-45 female connector (cable integrated type)
Recommended total extended
cable length: 1 m {3.28 feet}
25
