Panasonic WV-SW396

5-5
EXPLODED VIEW (5/9)
M57
M103
M58
M60
M55
M94
PCB5
M103
M56
M54
M53
M94
M103
PCB6
Cable Clamp
M63
M62
M103
M61
E17
M103
CAMERA UNIT-2
(Refer to the page 5-6.)
MAIN CHASSIS UNIT
(Refer to the page 5-8.)
PAN ROTARY UNIT
(Refer to the page 5-8.)
CAMERA UNIT-1
