REPLACEMENT PARTS LIST
Important Notice
1. Components identified by " Y " mark have special characteristics important for safety.
When replacing any of these components, use only manμFacturer's specified parts.
2. RTL : Retention Time Limited (No longer available after discontinuing product).
3.
marked parts are the new parts.
REF. NO. PART NO. DESCRIPTION
MISCELLANEOUS FOR WV-SW396
REF. NO. PART NO. DESCRIPTION
MO1
Y
L6FCYYYH0061 Fan
FL1 J0KD00000059 Ferrite Core for Sensor FPC
FL2
Y
J0KD00000060 Ferrite Core for Tilt FPC
E11
Y
VSW395RZ5A Sensor FPC (Flexible Printed Circuit) for
Sensor Board CN1and Main Board CN6
E12
Y
VSW395RZ8C Tilt FPC (Flexible Printed Circuit) for Main
Board CN8and Servo Board CN802,CN803
E13 K9ZZ00002318 Slipring
E14
Y
L9DGYY000009 Heater A
E15
Y
L9DGYY000010 Heater B
E16 L9ZZ00000243 Dehumidification Element
E17 PGWD1027ZA4P Tilt Heater Cable
E18 K1V9ZZY00015 Housing Base Cable Ass'y
E19
Y
K1V9ZZY00010 Heater Cable
E20
Y
K1V9ZZY00011 Entrance Cable for I/F Board CN501, CN510
M1 V1AA1109A4 Special Screw
M2
Y
V5YB0528AN Safety Wire
M3 PGKV1025ZAC1 Main Sunshield
M4
Y
3DA003803AAA Main Sunshield Rear Cover
M5 3CU001205AAA SD Sunshield Connectirng Plate
M7
Y
3PC001524AZA Shock Mark Label
M8
M9
Y
3PC001496AAA FCC/DOC Label
M10 PGQT1115ZAC1 Type Indication Label
M11
Y
PGGT1059YAC1 Main Labele
M12 3CB004257BAA SDHC Memory Card Front Plate
M13 3PD004349AAA SDHC Memory Card Slot Label
M14 3CW001263AAA Coil Spring (Attachment Lock)
M15 3AB001262AAB Binding Head Screw
M16 3CE002713AAA Water-resistant Cap
M17
Y
3CX002046AAA SDHC Memory Card Slot Packing
M18 3CB004258AAA SDHC Memory Card Lock Plate
M19 V1AA1105B4 Dome Stopper Screw
M20 PGUW1007ZAC1 Dome Waterproof Ring
M21
Y
PGHG1017ZAC1 Dome Sealing Packing
M22 3DA003848AAA Dome Cover
M23 PGUW1008ZAC1 Dome attachment
M24
Y
PGHG1018ZAC1 Dome Attachment packing
M25 3KA001390AAA Heatsink
M26 3KB001347AAA Cool Sheet (17x14)
M27
Y
3CH001796AAA Heater Terminal
M28 3KA001394AAA Heater Cover R
M29 3KA001393AAA Heater Cover L
M30 3CV002911AAA Battery Cushion
M31 3KB001335AAA Cool Sheet
M32 PGMC1012ZAC1 Shield Cover
M33
Y
PGKV1023ZAC1 Inner Cover
M34 PGMC1014ZAC1 Tilt FPC Shield
M35 3KB001348AAA Microwave Absorber Sheet
M36 3CB004224AAA Fan Mounting Plate
M37 3CL001301AAA Locking Wire Saddle
M38
Y
V7SA4570A4 Fuse Replacement Label
M39 3AA001112AAA Stepped Screw
M40 3CC002236AAA Connector Mounting Plate
M41
Y
3CX001594AAA Housing Base Waterproof Sealing Packing
M42 V1EA1063C4 Removable Screw
M43 3CW001420AZA Positioning Spring
M44
Y
3CE002712AAA Dome Housing
M45
Y
3CX001565AAA Sealing Packing
M46 3CZ001118AAA Barriar
M47 3CX002004AZA Protection Sealing
M48 3DC001076AAA Hook to Prevent Incorrect Insertion
M49
Y
PGGT1063ZAC1 Simple Main Label
M50 M3AA1044A4 Micro-Tex
M51
Y
3CE002342AAB Housing Base
M52 3CW001320AAA Waterproof Spring
M53 1FC001019AAA Bearing
M54 3CW001382AAA Tilt Spring
M55 1FC001018AAA Bearing
M56
Y
3CB004111AAA Tilt Chassis B
M57 9A0A0251BB Tilt Gear Ass'y
M58 3CJ001909AAA Motor Spacer
M60 PGVF1041ZAC1 Tilt, PAN Motor
M61
Y
3CB004109AAA Tilt Chassis A
M62 3CL001281AAA Tilt FPC Holder
M63
Y
3CB004110AAA PAN Chassis
M64
Y
3DA003772AAA Lens Cover
M65 PGMC1019ZAC1 Microwave Absorber
M66
Y
3FF001047BAA Tilt Gear
M67 3CH001779BAA Tilt Core Holder
M68 3CL001282CAA Tilt FPC Holder
M69 PGMC1015ZAC1 Shield Plate B
M70 9A0A0286AA Lens Flame L Ass'y
M71 Magnet
M72 Zoom Lens Ass'y (Not supply)
M73 3CV002859AAA Floating Rubber
M74 9A0A0287BA Lens Flame R Ass'y
M76 9A0A0250BB PAN Gear Ass'y
M77 PGMH1042ZAC1 Camera Mounting Plate
M78 3CH001803AAA PAN Magnet Holder
M79
Y
3FF001048BAA PAN Gear
7- 1
YWVMGA0502AN
MAC Code Label (Not supply)
