User Manual For Cyclone LC Programmers 149
17 TECHNICAL INFORMATION
This section contains information about various physical, mechanical, electrical, etc. aspects of the
Cyclone LC programmers, part # CYCLONE-LC-ARM and part # CYCLONE-LC-UNIV. The
information applies to both Cyclone LC part numbers unless specified.
17.1 Life Expectancy
Start Button: 1 Million Press Rated
17.2 Electrical Specifications
Input Voltage: DC 6V
Maximum Current: Up to 2A (0.6A typical) @ 6V
17.3 Mechanical Specifications
Dimensions: 8” L x 4” W x 1.25” H (20.3cm L x 10.2cm W x 3.2cm H)
Weight: 12.7 oz (360 g)
17.4 Electromechanical Relays
Max Recommended Switched Voltage: DC 24V
Max Recommended Switched Current: 1A
Output Voltage To Debug Port (when configured for internal power): DC 2V-5V
Max Current To Debug Port (when configured for internal power): 0.5 A
17.5 Debug Ports - CYCLONE-LC-ARM
Ports A, B: 0.05” (1.27 mm) Pitch
Ports C,: 0.1” (2.54 mm) Pitch
Characteristic Impedance: 50 ohms (all ports)
17.6 Debug Ports - CYCLONE-LC-UNIV
Ports A, B: 0.05” (1.27 mm) Pitch
Ports C, D, E, F, G, H: 0.1” (2.54 mm) Pitch
Characteristic Impedance: 50 ohms (all ports)
17.7 International Shipping
HTS Number: 8471500150
ECCN: EAR99
17.8 Compliances/Standards
ROHS Compliant
CE Certified
FCC Certified
More information on PEmicro’s Cyclone programmers is available at: pemicro.com/cyclone.
