User Manual For Cyclone LC Programmers 46
5.2.3.3.3 Set Date Formatting
Allows you to select how the date is displayed. The options are:
1. YYYY-MM-DD
2. MM-DD-YYYY
3. DD-MM-YYYY
4. MM/DD/YYYY
5.2.3.3.4 Set Time Formatting
Allows you to select how the time is displayed. The options are:
1. HH:MM (24-hour)
2. HH:MM (AM/PM)
3. HH:MM:SS (24-hour)
4. HH:MM:SS (AM/PM)
5.2.3.4 Configure AUX Button
Allows the user to configure an auxiliary (AUX) button which (if configured) will be labeled
appropriately and displayed to the left of the Menu button on the Cyclone’s touchscreen LCD.
When pressed, the AUX button will perform the task for which it has been configured. The options
that may be assigned to the AUX button are:
1. No Operation - No operation is assigned to the AUX button and it will not be displayed on
the LCD screen.
2. Perform Verify Only - Verifies the data on the target device against the data in the pro-
gramming image.
3. Toggle Power - Toggles the Cyclones power relays off/on.
4. Validate Image CRC32 - Validates the CRC32 of the data on the target device against that
of the data in the programming image.
5. Power Cycle Device To Run User Code - Toggles the target power and maintains tri-state
mode for all signals.
6. Launch Image Programming - Launches the selected programming image. Replaces the
hardware Start Button.
5.2.3.5 Configure Screen
This menu presents options that allow the user to adjust or customize the Cyclone’s LCD
touchscreen display in various ways.
5.2.3.5.1 Change Screen Brightness
Allows the user to adjust the brightness of the LCD touchscreen. The “Increase” and “Decrease”
buttons will raise or lower the brightness level, respectively, in increments of 10%. Brightness can
be adjusted from between 100% - 10%. Press “Done” to exit.
5.2.3.5.2 Calibrate Screen
Allows the user to click on specified points on the LCD touchscreen in order to calibrate the
accuracy of the touch function. Follow the on-screen instructions.
5.2.3.5.3 Set Progress Details
This configures the display to present more detailed information during the progress of
programming, including the specific programming steps that are performed and specific
information about the programming and verifying procedure. The user may select “Show Details,
Keep Last Progress On,” “Show Progress Details,” or “Hide Progress Details.”
