Tag’s LED indicator
When inserting battery:
0 flashes – battery is discharged.
1 flash – low battery level.
3 flashes – high battery level.
Short tag’s button press:
0 flashes – battery is discharged.
1 flash – tag works normally.
WARNING!
DO NOT ALLOW ANY MOISTURE TO REACH IMMOBILIZER
TAG. KEEP TAG AT A CONSIDERABLE DISTANCE FROM THE
MAGNETS OR PRODUCTS WITH THEIR OWN MAGNETIC
FIELD.
Replacing immobilizer tag battery
Low battery level is confirmed with 3 beeps per minute (from beeper,
see System set, page 4) when the ignition is switched on. Battery should be
replaced if it sounds.
To check the battery when there is no connection with the base unit,
shortly press built-in tag’s button: LED indicator will confirm serviceability of
battery with 1 flash. If LED indicator is lit for longer, or does not light at all, the
tag’s battery should be replaced.
