Esprit 728 Ultra & 738 Ultra 17
6.1 Reporting Options
Feature Select Programming D Address 086; Keys [STAY] and [AWAY]/[FORCE]
Default: Reporting Disabled
When a specific event occurs in the system, the control panel will attempt to report the appropriate event code (if programmed) to
the monitoring station. The four available Reporting Options described in Table 4, define where the event codes are reported. In
order to establish communication with the monitoring station, the control panel will first access a telephone line and wait a
maximum of 8 seconds for a dial tone. If a dial tone is recognized, or if after 8 seconds there is no dial tone, the control panel will
dial the appropriate Monitoring Station Telephone Number (MSTN) as defined by the Reporting Options listed in Table 4. If
communication is established, the control panel will transmit the events in the event buffer to the monitoring station. If
communication fails during transmission, the control panel will dial the next MSTN, as defined by the reporting options listed
below, and report only those events not reported during the interrupted attempt. For more information see Reporting Event Codes
on page 22.
[
ENTER] + Installer code + [0] [8] [6] + [STAY] and [AWAY]/[FORCE] ON/OFF + [ENTER]
6.1.1 Reporting Disabled
The control panel will never transmit any event codes to the monitoring station.
6.1.2 Regular Reporting
Using Regular reporting, the event codes are reported to the monitoring station using either telephone number 1 or 2.
The control panel will begin by dialing Monitoring Station Telephone Number 1 (MSTN1). If communication fails, the
dialer will hang up, wait a predetermined period and dial MSTN2. This sequence will repeat 4 times, switching back
and forth between the 1st and 2nd number (see Figure 26 on page 18) until communication is established. After eight
unsuccessful attempts, the redial sequence ends and a "communicator report failure" will appear in the keypad's
trouble display (key [7] ON). When the next event occurs (reportable or non-reportable), the control panel will begin
the dialing sequence again.
6.1.3 Split Reporting
When the system is not in alarm, the control panel will report all Event codes to Monitoring Station Telephone 2
(MSTN2). If communication fails, the dialer will hang-up, wait a predetermined period and dial the number again. The
control panel will dial the number eight times until communication is established (see Figure 26 on page 18). After eight
unsuccessful attempts, the redial sequence ends and a "communicator report failure" will appear in the keypad's
trouble display (key [7] ON). When the next event occurs (reportable or non-reportable), the control panel will begin
the dialing sequence again.
When the system is in alarm, the control panel will report all Event codes to MSTN1. Any ongoing communication
(upload/download or reporting to Telephone 2) will stop immediately and the panel will dial Telephone 1. If
communication fails, the dialer will hang-up, wait a predetermined period and dial the number again. The control panel
will dial the number eight times until communication is established (see Figure 26 on page 18). After eight
unsuccessful attempts, the redial sequence ends and a "communicator report failure" will appear in the keypad's
trouble display (key [7] ON). When the next event occurs (reportable or non-reportable), the control panel will begin
the dialing sequence again.
6.1.4 Double Reporting
In double reporting, the control panel will report each event code to both Monitoring Station Telephone Numbers
(MSTN). The control panel will begin by attempting communication with MSTN1 and if communication fails, the dialer
will hang-up, wait a predetermined period and dial the number again. The control panel will dial the number eight times
until communication is established (see Figure 26 on page 18). After eight unsuccessful attempts, the redial sequence
ends and a "communicator report failure" will appear in the keypad's trouble display (key [7] ON). If communication has
been established and the event codes transmitted, or if after eight attempts communication has not been established,
the control panel will report the same Event codes to MSTN2.
Table 4: Reporting Options
Key [
STAY] Key [AWAY]/[FORCE] Reporting Feature
OFF OFF Reporting Disabled
OFF ON Regular Reporting
ON OFF Split Reporting
ON ON Double Reporting
