22 Reference & Installation Manual
6.9 Reporting Event Codes
Streamline - Sections 11 to 67
D
Hex Programming - Addresses 300 to 527
An Event code is a 2-digit hexadecimal value, consisting of numbers from 00 to FF. Each address between 300 and 527
represents a specific event, as described below and in the 728 Ultra & 738 Ultra System Programming Guide. When an event
occurs in the system, the control panel will attempt to transmit the 2-digit Event code programmed at the corresponding address
to the monitoring station. The method of Event code transmission is dependent on the Communicator Formats (see page 19) and
the Reporting Options (see page 17).
You do not need to program addresses 300 to 527 if using the Ademco Contact I.D. (all codes) format. If you plan to
program most of the event code addresses, we suggest you use the Hex Streamlined Section Programming Method as
described on page 13. Otherwise, use the Hex Programming Method as described on page 12.
6.9.1 Arming Codes
Streamline - Sections 11 to 23
D
Hex Programming - Addresses 300 to 349
Whenever the system is armed, the control panel will send the programmed event code to the monitoring station
identifying who armed the system or how the system was armed.
6.9.2 Disarming Codes
Streamline - Sections 23 to 35
D
Hex Programming - Addresses 350 to 399
Whenever the system is disarmed, the control panel will send the programmed event code to the monitoring station
identifying who disarmed the system.
6.9.3 Alarm Codes
Streamline - Section 36 to 38
D
Hex Programming - Addresses 400 to 409 (728 Ultra)
Streamline - Section 36 to 40
D
Hex Programming - Addresses 400 to 417 (738 Ultra)
Whenever an alarm occurs, the control panel will send the programmed event code to the monitoring station identifying
which zone generated an alarm.
6.9.4 Restore Codes
Streamline - Sections 42 to 44
D
Hex Programming - Addresses 424 to 433 (728 Ultra)
Streamline - Sections 42 to 46
D
Hex Programming - Addresses 424 to 441 (738 Ultra)
The control panel will send the programmed event code to the monitoring station as soon as the zone closes after
having generated an alarm, or as soon as the zone closes after bell cut-off. For more information, please see Report
Zone Restore Options on page 24.
6.9.5 Zone Shutdown Codes
Streamline - Sections 48 to 50
D
Hex Programming - Addresses 448 to 457 (728 Ultra)
Streamline - Sections 48 to 52
D
Hex Programming - Addresses 448 to 465 (738 Ultra)
If the Auto Zone Shutdown (see page 30) feature is enabled, the control panel will send the programmed event code to
the monitoring station identifying which zones were shut down.
6.9.6 Tamper Codes
Streamline - Sections 54 and 55
D
Hex Programming - Addresses 472 to 478 (728 Ultra)
Streamline - Sections 54 and 55
D
Hex Programming - Addresses 472 to 479 (738 Ultra)
If the Tamper/Wire Fault Recognition Options (see page 38) are disabled, the control panel will never transmit these
event codes. Otherwise, whenever a tamper occurs on a zone, the control panel will send the programmed Event code
to the monitoring station. With Advanced Technology Zoning (ATZ) enabled (see page 27), each Tamper code address
will represent two zones (e.g. for 728 Ultra, Tamper 1 = zones 1 & 2, Tamper 3 = zones 3 & 4, and for 738 Ultra,
Tamper 1 = zones 1 & 9, Tamper 2 = zones 2 & 10, etc.). The control panel will send the programmed Event code when
a tamper occurs on either zone.
Table 10: Tamper/Trouble Zone Recognition
728 Ultra & 738 Ultra
Without ATZ
728 Ultra
With ATZ
738 Ultra
With ATZ
[472] - Tamper 1 = Input 1/Zone 1 [472] - Tamper 1 = Input 1/Zones 1 & 2 [472] - Tamper 1 = Input 1/Zones 1 & 9
[473] - Tamper 2 = Input 2/Zone 2 [474] - Tamper 3 = Input 2/Zones 3 & 4 [473] - Tamper 2 = Input 2/Zones 2 & 10
[474] - Tamper 3 = Input 3/Zone 3 [476] - Tamper 5 = Input 3/Zones 5 & 6 [474] - Tamper 3 = Input 3/Zones 3 & 11
[475] - Tamper 4 = Input 4/Zone 4 [478] - Tamper 7 = Input 4/Zones 7 & 8 [475] - Tamper 4 = Input 4/Zones 4 & 12
[476] - Tamper 5 = Input 5/Zone 5 (738 Ultra only) [476] - Tamper 5 = Input 5/Zones 5 & 13
[477] - Tamper 6 = Input 6/Zone 6 (738 Ultra only) [477] - Tamper 6 = Input 6/Zones 6 & 14
[478] - Tamper 7 = Input 7/Zone 7 (738 Ultra only) [478] - Tamper 7 = Input 7/Zones 7 & 15
[479] - Tamper 8 = Input 8/Zone 8 (738 Ultra only) [479] - Tamper 8 = Input 8/Zones 8 & 16
