Paradox 738ULT User Manual

Esprit 728 Ultra & 738 Ultra 25
Part 7: Zone Definitions
Figure 27: 728 Ultra Zone Related Features
Zone Speed
(applies to all zones)
Address 053
EOL Zones
(applies to all zone inputs)
Address 088; [
MEM] key
ATZ Zone Doubling
(applies to all zone inputs)
Address 090; key [8]
Address 090; key [7]
Partitioning
(applies to entire system)
Address 086; key [8]
System A/Stay Zones
Address 116; Keys [1] to [10 (0)]
Note: If the system is not partitioned,
zones will be defined as Stay zones
System B Zones
Addresses 120; Keys [1] to [10 (0)]
Bypass Enabled Zones
Address 124
Keys [1] to [10 (0)]
Auto Zone Shutdown
Address 086; [
TRBL] key
Zone Definitions
Up to 10 zones can be
independently
programmed (defined).
Keypad Zone 1 & 2 Supervision
Enabled/Disabled
Address 090;
Keys
[STAY] & [AWAY]/[FORCE]
Independent Zone
Definitions
Only one of these options
can be assigned to a
zone. If a zone is assigned
more than one option, the
control panel will apply the
option with the highest
priority (1 to 5).
Intellizones
Address 092
Keys [1] to [10 (0)]
Intellizone
Time Delay
Address 057
Silent Zones
Address 096
Keys [1] to [10 (0)]
24Hr/Fire Zones
Address 100
Keys [1] to [10 (0)]
Generates
Report Only
Address 086
Key [9]
Enable/
Disable
Zone 4
Address 090
Key [1]
Only if zone
3 is defined
fire zone and
ATZ is
enabled
Instant Zones
Address 104
Keys [1] to [10 (0)]
Follow Zones
Address 108
Keys [1] to [10 (0)]
Delay 2 Zones
Address 112
Keys [1] to [10 (0)]
Entry Delay 2
Timer
Address 051
Delay 1 Zones
Zone not defined as
any of the above will
default to Delay 1
Entry Delay 1
Timer
Address 050
Zone Related
Features
