44 Reference & Installation Manual
11.12.7 Timer Loss - Key [8]
The illumination of the [8] key indicates that the control panel’s internal clock must be reprogrammed. To reprogram
the timer press:
[ENTER] + (Installer, Master or User code 1) + [MEM] + 2 digits (00 to 23) representing hours + 2 digits (00 to 59)
representing minutes + [ENTER]
11.12.8 Tamper/Zone Wiring Failure - Key [9]
If the Tamper/Wire Fault Recognition Options (see page 38) are enabled, the [9] key will illuminate to indicate a short
or cut on a zone input. In order to provide line short recognition the zone connections must have EOL resistors (see
Keypad Zone Connections on page 5 to Single Zone Input Terminal Connections on page 6).
11.12.9 Telephone Line Monitoring - Key [0]
If the Telephone Line Monitoring (TLM) feature (see page 37) is enabled, the [0] key will illuminate to indicate that the
control panel has not detected the presence of a telephone line for 30 seconds.
11.12.10 Fire Loop Trouble - Key [STAY]
The illumination of the [STAY] key indicates a wiring problem (line open) on zone 3 (or zone 5 with 2-wire smoke and
ATZ for 728 Ultra), if identified as a fire zone (see 24Hr and 4-Wire Smoke Detector Fire Zones and 2-Wire Smoke
Detector Recognition (Input 3) on page 28).
11.13 Key Access Programming
This method allows for quick programming of features without entering addresses or section numbers. The following features are
programmed using the Installer code as well as the Master code and User code 1.
Key Features
[9]
[MEM]
[BYP]
[TBL] / [TRBL]
[AWAY] / [FORCE]
[
STAY]
[8]
Auto Arm Time: for details see page 32
Panel Time: for details see page 38.
Manual Test Report: for details see page 24
Call Espload: for details see page 15
Answer Espload: for details see page 15
Cancel Communication: for details see page 15
Installer Test Mode: for details see page 39.
