14 User Guide
Figure 2: Single Residence with One or Two Sleeping Areas
Smoke detectors should be installed as close to the center of the ceiling as possible.
Standard Fire Zones
During a fire alarm, the siren emits an intermittent sound (BEEP-
BEEP-BEEP) until silenced or reset. If the zone is a Standard Fire
Zone, your system can immediately send an alert to your
monitoring station. To disarm a false alarm:
Dining Room Kitchen
Living Room
Bedroom
Bedroom Bedroom
= Smoke detectors for minimum security.
= Smoke detectors for additional security.
Sleeping
area
Bedroom
Bedroom
Bedroom
Bedroom
Family Room
Living Room
Kitchen
Bedroom
Bedroom
Living Room
Kitchen
Bedroom
Bedroom
Family Room
Sleeping
areas
Single Residence with One Sleeping Area Single Residence with Two Sleeping Areas
User code
Call your monitoring station
quickly to advise them of the
false alarm.
Magellan_EU03.fm Page 14 Friday, December 3, 2004 2:33 PM
