8 User Guide
Magellan’s Keypads
Use this keypad to enter User
codes, required data and/or to
select desired menus.
Main Keypad
Center Keypad
Use keys [1] to [16] on the center keypad for the following:
Zones 1 to 16*
OFF = Zone closed (ok)
ON = Zone opened
Flashing = The zone has been tampered with
Press once = Listen to zone’s label (e.g.: “Front door”)
* = Press and hold key [16] to listen to the label for zone 16. See
Key [16] below for more information.
Users 1 to 16
When programming a user:
OFF = User not programmed
ON = User programmed
Press once = Listen to user label and program or edit a user
X10 programming
This keypad is also used when programming and using
Magellan’s X10 features. Refer to Magellan’s X10 Instruction
Guide which can be downloaded for free from our website at
www.paradox.ca.
Key [16]
Press once = Make a telephone call or answer an incoming call.
Press again to hang up. See page 21.
Press & hold = Listen to the zone label of zone 16.
Fast flashing = Speakerphone in use. See page 21.
Magellan_EU03.fm Page 8 Friday, December 3, 2004 2:33 PM
