PART 9: REPORTING AND DIALER SETTINGS
The following section explains all the features and options that must be programmed in order for your security system to properly report
system events to a central station. When an event (e.g. zone in alarm) occurs in the system, the control panel verifies if a report code was
programmed in the section corresponding to the event (except Ademco Contact ID “All Codes”). If a report code was programmed, the
control panel will dial the central station telephone number defined by the Event Call Direction feature. When the central station answers,
the control panel will transmit the System Account Code, followed by the programmed Report Code.
Figure 9.1: Event Reporting
Reporting/Dialer
Option [3] - Section [135]
Partition Account
Numbers
Partition Account Number 1
3 or 4 digits (0-F) in section [143]
Partition Account Number 2
3 or 4 digits (0-F) in section [144]
Central Station Telephone Numbers 1 & 2
Defines which Central Station Telephone Numbers each group of
events will report to.
Section [137]
Option [1] ON = Call Telephone #1 for Arm/Disarm Report Codes
Option [2] ON = Call Telephone #2 for Arm/Disarm Report Codes
Option [3] ON = Call Telephone #1 for Alarm/Restore Report Codes
Option [4] ON = Call Telephone #2 for Alarm/Restore Report Codes
Option [5] ON = Call Telephone #1 for Tamper/Restore Report Codes
Option [6] ON = Call Telephone #2 for Tamper/Restore Report Codes
Section [138]
Option [1] ON = Call Telephone #1 for Trouble/Restore Report Codes
Option [2] ON = Call Telephone #2 for Trouble/Restore Report Codes
Option [3] ON = Call Telephone #1 for Special System Report Codes
Option [4] ON = Call Telephone #2 for Special System Report Codes
Central Station Telephone Numbers 1 & 2
Sections [151] & [152]
Back-up Number
Section [153]
Related Features
Delay Before Alarm Transmission
Section [080]
Pager Format Delay Transmission
Section [083]
Recent Closing Delay
Section [085]
Power Failure Report Delay
Section [086]
Auto Test Report
Sections [087] & [110]
Report Disarm Options
Option [1] - Section [131]
Report Zone Restore Options
Option [6] - Section [132]
Alternate Dial
Option [4] - Section [136]
Maximum Dialing Attempts
Section [081]
Delay between Dialing
Attempts
Section [136]
Reporting Formats
Section [140]
1
st
digit = CSTN#1
2
nd
digit = CSTN#2
Program 1 or 2-digit
(1 - FF) report codes
into sections [160]
to [213] where each
section represents
up to four events in
the system.
Program the 2-digit report codes
corresponding to the Contact I.D.
Table into sections [160] to [213]
where each section represents
up to four events in the system.
Program FF to use the default
Contact ID Report Code.
The control panel
automatically generates
all report codes. You do
not have to program
any report codes.
DTMF
(Tone)
[5] = Ademco Contact ID
[6] = Pager
[4] = Ademco Express
“Programmable”
Option [3]
OFF - Section [136
]
“Programmable”
Option [3] ON - Section [136
[2] = Silent Knight Fas
t
Pulse
[1] = Ademco Slow
[3] = Sescoa
Partition 1
Partition 2
