4
REFERENCE & INSTALLATION MANUAL
1.3 DETECTORS, KEYPADS AND EXPANSION MODULES
If you would like to obtain more information on our line of keypads, security system accessories or other security products, please
contact your local Paradox distributor or visit our web site at http://www.paradox.ca.
1.3.1 SPECTRA 1686H AND 1686V 10-ZONE LED KEYPADS
The elegant Spectra 1686H/1686V LED keypads’ patented “Key
Light” feature provides a user-friendly display of the system’s current
status. For example, if zone 5 is open, the [5] key turns on. What
could be simpler? Designed to be compatible with any Spectra Series
control panel, our Euro-style Spectra keypads eliminate stocking and
ordering concerns.
1.3.2 SPECTRA 1689 16-ZONE LED KEYPADS
The Spectra 1689 LED keypad’s brilliant display provides instant
feedback of the system’s current status. Designed to be compatible
with any Spectra Series control panel, this ergonomic and user-
friendly keypad will complete any installation.
1.3.3 SPECTRA 1641 LCD KEYPAD
The 1641 is a 32-character programmable LCD keypad which
includes a zone input as well as a PGM output. View zone, event and
trouble status for one or more partitions, display entry/exit delay,
adjust contrast, backlight, and many other features. Most messages in
the LCD keypad are programmable.
1.3.4 OMNIA 433MHZ WIRELESS TRANSMITTERS
With their encrypted wireless communication protocol and code-
hopping technology, the Omnia series transmitters offer reliability and
security. Operating at 433MHz, the series includes the Motion
Detector (OMN-PMD1), Door Contact (OMN-DCT1) and Remote
Control (OMN-RCT1).
1.3.5 ZONE EXPANSION BUS MODULES (NOT UL LISTED)
Connected to the Spectra control panel’s communication bus, the fully
supervised zone expansion modules provide you with up to four
(SPC-ZX4 and APR3-ZX4) or up to eight (SPC-ZX8 and APR3-ZX8)
additional hardwired inputs and one normally open 50mA PGM output
(SPC-ZX8 and APR3-ZX8 only). Due to its Auto-Panel Recognition
feature, modules with the APR3- prefix are compatible with Spectra,
Digiplex and DigiplexNE.
