PGC, Inc. Appendix B; SmartPad version 0.503 Steady State & Programmable
November 2005 B-11
Right Nibble Definition
Data Reconfigure Mode
x0 NO NO ACTION
x1 NO NO ACTION
x2 NO NO ACTION
x3 NO NO ACTION
x4 YES CASCADE MODE
x5 YES TWO TEMPERATURE MODE
x6 YES DRY MODE
x7 YES SLOW DAMPER MODE
x8 NO NO ACTION
x9 NO NO ACTION
Programming examples:
PRGC = 00
All digital outputs are off.
System will not reconfigure.
PRGC = 10
Digital output #1 is on.
System will not reconfigure.
PRGC = 04
All digital outputs are off .
System will reconfigure to mode 00 (Cascade mode)
PRGC = 14
Digital output #1 is on.
System will reconfigure to mode 00 (Cascade mode)
PRGC = 16
Digital output #1 is on.
System will reconfigure to mode 02 (Dry mode)
