PGC, Inc. Appendix B; SmartPad version 0.503 Steady State & Programmable
November 2005 B-19
Factory Configuration Menu (Steady State and Prog Modes)
Entering 7178 in the access code field will display the factory configuration menu. This
menu will allow the user to re-configure the SmartPad™ for various operating modes
and/or set point entry options.
The top line of the display will indicate the current operating mode.
The second line of the display is the current value that can be accessed.
The third line of the display is the current setting for the displayed value. Pressing
CHNG (F3) will toggle the displayed value through all possible settings. The setting that
is displayed is the setting that will become active.
Press ENTER (F4) to exit the alarm control menu and return to the process variable
screen. This will cause the system to reboot in the mode selected.
Label Displayed Acceptable Data
Range
Description
CHOOSE CONTROL MODE Rh Cascade
Two Temp
Dryer
Slow Damper
Will reconfigure the SmartPad™
control mode. Use caution when
changing modes. The operating
mode is often hardware specific.
CHOOSE SP ENTRY MODE Steady State
Programmable
Will reconfigure the SmartPad™ set
point entry mode. If a single
condition is require, steady state is
the most user-friendly mode. If
multiple conditions that change
automatically over time are required,
programmable mode is required.
