PGC, Inc. Appendix B; SmartPad version 0.503 Steady State & Programmable
November 2005 B-31
INPUT COMMANDS:
(Note: Sign byte is optional on inputs. Set point input commands may only be used in steady state modes)
Command Function
=OO<CR> Toggles current run state (On/Off command)
=RC<CR> Instructs Smart Pad to reboot in Rh Cascade control mode
=TT<CR> Instructs Smart Pad to reboot in Two Temperature control mode
=DY<CR> Instructs Smart Pad to reboot in Dryer control mode
=SD<CR> Instructs Smart Pad to reboot in Slow Damper control mode
=SS<CR> Instructs Smart Pad to reboot in Steady State set point entry mode
=PG<CR> Instructs Smart Pad to reboot in Programmable set point entry mode
=AS<SP>xx.xx<CR> Inputs xx.xx as the new Air Set point
=AH<SP>xx.xx<CR> Inputs xx.xx as the new Air Half proportional band
=AR<SP>xx.xx<CR> Inputs xx.xx as the new Air Reset rate
=AD<SP>xxx<CR> Inputs xxx as the new Air Derivative constant
=XS<SP>xx.xx<CR> Inputs xx.xx as the new auXiliary Set point
=XH<SP>xx.xx<CR> Inputs xx.xx as the new auXiliary Half proportional band
=XR<SP>xx.xx<CR> Inputs xx.xx as the new auXiliary Reset rate
=XD<SP>xxx<CR> Inputs xxx as the new auXiliary Derivative constant
The following command is available in Two Temperature mode only.
=WS<SP>xx.xx<CR> Inputs xx.xx as the new Water Set point
=WR<SP>xx.xx<CR> Inputs xx.xx as the new Water Reset rate
=WH<SP>xx.xx<CR> Inputs xx.xx as the new Water Half proportional band
=WD<SP>xx.xx<CR> Inputs xx.xx as the new Water Derivative constant
The following commands are available in a Cascade mode only.
=WL<SP>xx.x<CR> Inputs xx.x as the new Water Lower limit
=WU<SP>xx.x<CR> Inputs xx.x as the new Water Upper limit
=RS<SP>xx.xx<CR> Inputs xx.xx as the new Rh Set point
=RH<SP>xx.xx<CR> Inputs xx.xx as the new Rh Half proportional band
=RR<SP>x.xxx<CR> Inputs x.xxx as the new Rh Reset rate
=RD<SP>xxx<CR> Inputs xxx as the new Rh Derivative constant
The following commands are available in Slow Damper mode only.
=DH<SP>xx.xx<CR> Inputs xx.xx as the new Damper Half proportional band
=DR<SP>x.xxx<CR> Inputs x.xxx as the new Rh Reset rate
The following commands are available in programmable modes only.
=GO<CR> Instructs the program to run/resume
=ST<CR> Instructs the program to halt
=LUP<SP>xx<SP>yy<SP>zz<CR>
Inputs xx,yy,zz as the new loop (LUP) parameters [start seg; loop from seg;
loop to seg] This command will also reinitialize the loop at the new loop parameters.
=PR<SP>xx<SP>aa.a<SP>ww.w<SP>hh:mm:ss<CR>
Inputs the PRogram data, air (aa.a) and water
(ww.w) set points and time (hh:mm:ss), for the segment indicated (xx).
=IN<CR> Instructs the program to reIN
itialize the loop at the existing loop parameters.
