Parameter Generation and Control 9354-4250 - Page 63

PGC, Inc. Appendix B; SmartPad version 0.503 Steady State & Programmable
November 2005 B-22
RH CASCADE CONTROL
H2O Low Limit
00.00 to 99.99 (varies with
hardware)
Defines the minimum water
temperature set point that the system
will allow. This value is hardware
specific, but is usually set to prevent
freezing.
DRY MODE REACT
CONTROL
REACT Hi Limit
00.00 to 99.99 Defines the maximum reactivation
temperature set point that the system
will allow.
DRY MODE REACT
CONTROL
REACT Low Limit
00.00 to 99.99 Defines the minimum reactivation
temperature set point that the system
will allow.
RH DRYER CONTROL
Control Band
00.00 to 99.99 Defines the proportion (P) portion of
the desiccant dryer control loop.
RH DRYER CONTROL
Rate
00.00 to 99.99 Defines the rate or integral (I) portion
of the desiccant dryer control loop.
RH DRYER CONTROL
Derivative
000 to 999 Defines the derivative (D) portion of
the desiccant dryer control loop.
AIR DAMPER CONTROL
Control Band
00.00 to 99.99 Defines the proportion (P) portion of
the air bypass damper control loop.
AIR DAMPER CONTROL
Rate
00.00 to 99.99 Defines the rate or integral (I) portion
of the air bypass damper control loop.
