Parameter Generation and Control 9354-4250 - Page 75

F2 F3 F4F1
AIR ACTUAL 25.0°C
RH ACTUAL 50.0 %
SP OUT MORE
METER
F2 F3 F4F1
MONITOR SET POINT
AIR SETPOINT 25.0°C
RH SETPOINT 50.0 %
TAB H2O ESC
STEADY STATE, CASCADE MODE
SCREEN PROGRESSION CHART VER 503
F2 F3 F4F1
H2O SETPOINT 15.0°C
H2O ACTUAL 15.0°C
ESC
WATER PARAMETERS
F2 F3 F4F1
* ALARM CONDITION *
ALARMS ARE DISABLED
ALARM DELAY 00:00:10
ACK RESET ESC
ALARM STATUS
(7178)
PREFERENCES
F2 F3 F4F1
ENTER YOUR LOCK OUT
ACCESS CODE:
REDO ESC
MORE
F2 F3 F4F1
SmartPad SN: 1234567
Software ver. 501f
STEADY STATE CASCADE
ALM PREF ESC
ENTRY MODE CHOICE
F3 F4
F1 F2
FACTORY SETUP
CHOOSE CONROL MODE
Two Temp
PREV NEXT CHNG ENTER
F1
AUX RTD CALIBRATION
F2 F3 F4F1
CHOOSE THE AREA
YOU WISH TO MODIFY
CODE ALRM CAL TUNE
AREA MODIFICATION
F2 F3 F4F1
NEW CODE
ENTER THE NEW LOCK
OUT ACCESS CODE:
REDO UNLOCK ESC
F2 F3 F4F1
TUNE MENU
STEADY STATE CASCADE
AIR HEATER CONTROL
Control Band 05.00
PREV NEXT ESC
F2 F3 F4F1
STEADY STATE CASCADE
GEN ALARM CONFIG
Alarms Enabled
PREV NEXT CHNG ENTER
ALARM MENU
F2 F3 F4F1
WATER CALIBRATION
H2O RTD CALIBRATION
REF. VALUE 63.9
ZERO SPAN NEXT ESC
F2 F3 F4F1
WATER ZERO
H2O RTD ZERO CALIB
ACTUAL VALUE 63.9
REF. VALUE 63.9
CAL DONE
F2 F3 F4F1
WATER SPAN
H2O RTD SPAN CALIB
ACTUAL VALUE 63.9
REF. VALUE 63.9
CAL DONE
F2 F3 F4
AUX RTD CALIBRATION
REF. VALUE 63.9
ZERO SPAN NEXT ESC
F2 F3 F4
AUX RTD ZERO
AUX RTD ZERO CALIB
ACTUAL VALUE 63.9
REF. VALUE 63.9
CAL DONE
F2 F3 F4
AUX RTD SPAN
AUX RTD SPAN CALIB
ACTUAL VALUE 63.9
REF. VALUE 63.9
CAL DONE
F1 F1
F1
F2 F3 F4F1
AIR HEAT OUT 50.0%
H2O HEAT OUT 50.0%
ESC
PERCENTAGE OUTPUT
