12. Release the belt tension.
13.
Loosen the bottom pulley on the non driven side of the belt.
14.
Remove the top Pulley from both sides of the belt to allow removal of the belt. Use a
13MMWrench on the back nut that secures the pulley, and secure the front of the pulley with
anadjustable wrench.
