Aligning the Top Camera
4.
Examine the contents side images for even black spacing on both sides of the bag.
a. Press 'Start' on the InspectRx and press stop when bags are aligned within the viewer
screen,run at least 20 bags through in order to verify the curve of the bags has moved past
the viewingscreen.
b. Click on ‘View’ on the top left of the screen to view the live image from the top Camera.
(topcamera images are the top two images)
c.
If spacing is less than the minimum of 1-2mm on both the top and bottom of the bag, adjust
theMarlin Camera (top) Angle.
