Parker 590C User Manual

590 Series DC Digital Drive Programming
D-77
MULTIPLEXER
Each block collects together 16 Boolean input values into a single word.
For example, one may be used to collect individual bits within a word for efficient access from a
communications master.
MULTIPLEXER
Parameter Tag Range
INPUT 0 to INPUT 15 1129 to 1144 FALSE / TRUE
The Boolean inputs to be assembled into a single word.
OUTPUT 1128 0x0000 to 0xFFFF
The resulting word.
