Read down the nearest operating pressure column until you arrive at a rating equal to or greater than
your equipment; then read to the left for dryer model
TW75 60 80
100 120 140
TW100 49 62
75 88 101
TW130 70 8
107 126 144
TW200 88 111
135 159 182
TW250 130 165
200 235 270
TW300 163 206
250 294 337
TW400 195 248
300 352 405
TW500 261 330
400 470 540
TW600 332 421
510 599 688
TW800 524 661
800 940 1079
TW1000 651 826
1000 1175 1359
TW1200 782 991
1200 1410 1619
TW1500 975 1239
1500 1762 2024
TW2000 1303 1652
2000 2350 2698
TW2600 1694 2147
2600 3054 3508
TW3000 1954 248
3000 3524 4048
TW4000 2600 3300
4000 4600 5400
TW5000 3200 4100
5000 5800 6700
Heatless
Model PRESSURE
EXAMPLE: You want to dry 95 SCFM at 80 PSIG - go to the 80 PSIG column and read down to 111 (this
is the first number equal to or greater than your requirement). Now read the dryer model number to you
left. A model TW-130 is required.
Sizing is approximate only. Consult factory for exact sizing. Downsizing could cause pressure
rop, bed fluidization, or poor dew point performance due to low contact time. d
The previous chart assumes 100°F or less inlet air temperature.
