PRESSURE DROP (PSID) OF THE ELEMENT
Element Initial PSID
Replacement
Element at PSID
Coalescer - Dry New 1.5 N/A
Coalescer - Wet New 2.5 6 - 8
Adsorber 1 4 - 6
Particulate 1.5 4 - 6
C
APACITY CORRECTION FOR FILTERS OPERATING AT NON STANDARD PRESSURES
Operating
PSI
Correction
Factor
Operating
PSI
Correction
Fac tor
0 PSI .13 100 PSI 1
10 PSI .3 110 PSI 1.08
20 PSI .44 120 PSI 1.11
30 PSI .52 130 PSI 1.16
40 PSI .61 140 PSI 1.19
50 PSI .7 150 1.22
60 PSI .76 160 PSI 1.28
70 PSI .83 170 PSI 1.34
80 PSI .9 180 PSI 1.38
90 PSI .95 200 PSI 1.40
Example: JL 1000-C operating at 130 PSI
Capacity of JL 1000-C (1000 CFM) x (1.16) = New Capacity 1116 CFM
