Gemini GT6 Hardware Installation Guide
System Overview
In this express setup procedure, we will give instructions for a Compumotor
system—Gemini drive with Compumotor motor, and Compumotor cables.
If you use non-Compumotor equipment, try to follow along and perform the steps
in the Express Setup procedure; consult Appendix A Specifications for additional
information you may need.
The next drawing shows the components of a Compumotor system.
RS-232/485
Cable
Motor
Cable
Gemini
Drive
Motor
AC
Power
Compumotor System
