17
Reference voltage, VREF
Instruction book, IQAN
Reference voltage, VREF
The IQAN module is internally equipped with a voltage regulator to generate the
reference voltage VREF. The standard reference voltage will feed different kinds of
sensors and potentiometers.
VREF positions.
NOTICE
It is strongly recommended to use the module’s -VREF and +VREF to all sensors and
potentiometers that are connected to the module inputs. This will reduce bad
measurement based on potential fault (i.e. different ground points for other supplies in
relation to the IQAN module ground, -BAT).
Maximum load for the VREF, see "Appendix A".
-VREF
+VREF
IQAN module

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Parker IQAN-MC2 and is the answer not in the manual?

Parker IQAN-MC2 Specifications

General IconGeneral
Input Voltage9-32 V DC
Supply voltage9-32 V DC
Number of CAN buses2
Number of digital inputs16
Number of digital outputs8
Number of analog inputs8
Protection classIP67
Digital Inputs16
Analog Inputs8
PWM Outputs4
CAN Interfaces2
Protection RatingIP67
Communication ProtocolsCAN, J1939
Processor32-bit
Operating Temperature-40 to +70 °C (-40 to +158 °F)
