5
IQAN-MC2
3 Product description
Instruction book, IQAN-MC2
3 Product description
IQAN-MC2
The IQAN-MC2 is designed for controlling hydraulic systems in vehicles and
machinery, using 12/24 Vdc power supply.
IQAN-MC2 is a master unit capable of running applications created by IQANdesign.
The MC2 has local I/O for input/output use and has two CAN busses that support ICP
(IQAN CAN Protocol), SAE J1939 and Generic CAN.
By supporting SAE J1939 and Generic CAN the MC2 can act as a sub-master when
there is a need of higher performance in a sub-circuit or when there is an OEM supplied
overall machine master.
This product is designed for the outdoor environment and comes with an IP6K9K
protection for applications where high-pressure water and steam jet cleaning is used.
The IQAN-MC2 module.
I/O overview
+BAT ADDR-H
ADDR-L
CAN-H
CAN-L
PORT 1
-BAT
+VREF
-VREF
USB
MC2
CAN-H
CAN-L
PORT 0
