Proportional Pressure Valves
Series RE*T / R*V
Operation Manual
19
Parker Hannifin Corporation
RE_-R_V obe_24-45-A-B 5715-651 UK 29.01.19
Parameter overview for basic mode
Parameter Description Unit
Parameter range
Default
setting
Comment
from up to
S5 ramp accel. channel A ms 0 32500 0
S6 ramp decel. channel A ms 0 32500 0
P3 MAX channel A % 50.0 100.0 100.0
P7 MIN channel A % 0.0 50.0 0.0
P11 polarity command – 0 1 0
E19
cable break detection
command
– 0 1 0
Codes R/S/4MA
only
E25 MIN operating threshold –
0 = 1%
0 = 1%
1 = 0.01%
Individual description of basic parameters
S5
ramp accel. channel A
Adjustment of ramp rate for increasing of the positive signal polarity.
To avoid switching noise.
S6
ramp decel. channel A
Adjustment of ramp rate for decreasing of the positive signal polarity.
To avoid switching noise.
P3
MAX +
Adjustment of maximum signal span for positive output signal.
To match the command signal span to the valve operating range.
P7
MIN +
Adjustment for positive output signal step at 0,1% command signal.
To compensate for the operate threshold of the valve function.
P11
command signal polarity
Adjustment of the command signal polarity.
To match the command signal polarity to the valve function.
E19
cable break detection
command
Adjustment of the operating mode for the command cable break
detection. To turn on resp. off of the cable break detection of the
command signal at a selected command signal option of 4...20 mA.
E25
MIN operating threshold
Adjustment of the MIN operating threshold.
To match the response sensitivity for the MIN-stroke step.
P5
dither amplitude
Adjustment of dither amplitude.
To reduce the influence of solenoid friction.
P6
dither frequency
Adjustment of dither frequency.
To match the dither signal to the valve dynamic.
Individual description of expert parameters
Parameter overview for expert mode
Para-
meter
Description Unit
Parameter Range
Default Setting Comment
from up to
P5 dither amplitude % 0 10.0
depending on
valve type
P6 dither frequency Hz 0 300
depending on
valve type
