9GB/CY
Introduction
12
Welding nozzle (0.8 mm)
13
Welding nozzle (0.9 mm)
14
Welding nozzle (1.0 mm)
15
Solid welding wire spool (aluminium)
Ø 1 mm / 200 g (pre-fi tted)
16
Flux-cored welding wire spool (steel)
Ø 1 mm / 200 g
17
Chipping hammer with wire brush
18
Feed roll
19
Shield body
20
Dark welding lens
21
Handle
22
Welding mask after fi tting
23
Mounting clip
24
Protective glass catch
25
Setting screw
26
Thrust roller unit
27
Roller holder
28
Feed roll holder
29
Wire outlet
30
Cable assembly bracket
31
Torch neck
32
Plug
33
Gas connection
34
MMA electrode holder
35
Welding mode selector key
36
Welding wire selector key
37
Voltage reducer selector key
38
Fixing ring
Technical specifi cations
Input power: 4.3 kW
Mains connection: 230 V~ 50 Hz
Weight: 8.6 kg
Fuse: 16 A
Welding with fl ux-cored wire:
Welding current: I
2
= 72–160 A
Duty cycle X:
20% at 160 A
welding current,
60% at 92 A
welding current
Open circuit voltage: U
0
= 53 V
Greatest rated value of
the mains current:
I
1max.
= 26.5 A
Effective value of the
greatest mains current:
I
1eff.
= 11.9 A
Welding wire reel
max.:
approx. 5000 g
Welding wire diameter
max.:
1.0 mm
Characteristic value Flat
MMA welding:
Welding current: I
2
= 63–140 A
Duty cycle X:
20% at 140 A
welding current,
60% at 81 A
welding current
Open circuit voltage: U
0
= 53 V
Greatest rated value of
the mains current:
I
1max.
= 26.3 A
Effective value of the
greatest mains current:
I
1eff.
= 11.8 A
Characteristic value Falling
TIG welding:
Welding current: I
2
= 63–200 A
Duty cycle X:
10% at 200 A
welding current,
60% at 82 A
welding current
Open circuit voltage: U
0
= 16.9 V
Greatest rated value of
the mains current:
I
1max.
= 28.2 A
Effective value of the
greatest mains current:
I
1eff.
= 8.9 A
Characteristic value Falling
Changes to technical and visual aspects
of the product may be made as part
of future developments without notice.
